JBL Control 65P/T-WH 5.25" PREMIUM RBI PENDANT SPK W RBI, WHT B-Stock
Share
In stock
- SKU
- C65P-T-WH-B
Description
JBL Control 65P/T-WH 5.25" Premium RBI Pendant Speaker with RBI, White
The Control 65P/T-WH is a compact coaxial pendant speaker engineered for overhead recording environments, voiceover booths, and acoustic treatment in home and project studios. Its lightweight construction and patent-pending Radiation Boundary Integrator (RBI) technology deliver focused, controlled acoustic projection without the beaming and phase issues typical of conventional ceiling speakers. The white finish integrates seamlessly into standard studio ceilings while maintaining professional audio fidelity for critical listening and monitoring applications.
Recording & Monitoring Performance
This speaker produces 86 dB nominal sensitivity with a rated maximum SPL of 105 dB continuous (111 dB peak), delivering articulate vocal and instrument capture with balanced frequency response across recording sessions. The 120° nominal coverage angle ensures even acoustic distribution throughout control rooms and isolation spaces, while RBI waveguide technology — adapted from JBL's VERTEC line arrays — minimizes phase distortion and acoustic dead zones that compromise mix accuracy during playback and reference monitoring.
Design & Build Quality
The 130 mm coaxial driver arrangement pairs a polypropylene-coated LF cone with a neodymium 20 mm textile soft-dome HF driver featuring ferro-fluid cooling for extended reliability during long studio sessions. Robust High Impact PolyStyrene (HIPS) construction with steel and rubber components provides durability in professional studio installations, while the compact 234 mm diameter footprint and 3.7 kg weight simplify positioning above acoustic panels, diffusers, or treatment arrays in tight studio overhead spaces.
Key Features
- 130 mm (5.25-inch) low-frequency driver with polypropylene-coated cone and copper voice coil
- 20 mm (3/4-inch) textile soft-dome tweeter with neodymium magnet and ferro-fluid cooling
- Coaxially mounted driver configuration for time-aligned output
- Patent-pending Radiation Boundary Integrator (RBI) with 200 mm diameter waveguide
- 75 Watts continuous pink noise (150 Watts program), 300 Watts peak power handling
- 8-ohm rated impedance
- 60W multi-tap 70V/100V transformer with six selectable taps (60W, 30W, 15W, 7.5W)
- Frequency response: 55 Hz – 20 kHz (-10 dB); 78 Hz – 18 kHz (±3 dB)
- Maximum SPL: 105 dB continuous, 111 dB peak at 1 meter
- 120° nominal coverage angle with ±20°/-10° characteristics
- Two removable locking euro-block connectors with screwdown terminals
- Compact 234 mm diameter, 259 mm height; 3.7 kg weight
The Control 65P/T-WH combines compact architectural fit with advanced acoustical engineering, making it the choice for studios where consistent overhead coverage and minimal visual clutter serve both control-room accuracy and session workflow.
More Information
| Condition | Refurbished |
|---|
Reviews
At a Glance
The JBL Control 65P/T-WH is a professional-grade pendant speaker designed for fixed installations where architectural blend and consistent acoustic fidelity are non-negotiable. Its coaxial driver pairing—130 mm polypropylene-coated LF cone with a 20 mm neodymium textile dome tweeter—delivers smooth, phase-coherent response from 78 Hz to 18 kHz (±3 dB), while RBI waveguide tech eliminates the comb-filtering and dead zones typical of conventional ceiling speakers. Ideal for background music systems, conferencing setups, and institutional audio where you need predictable, artifact-free sound across the entire listening plane without coloration or phase smearing.
Who This Is For
Great for
- ✓ Commercial installations
- ✓ Institutional audio
- ✓ Live Performance
- ✓ Conferencing
Not the best pick for
- – Home audio
- – High-fidelity music listening
- – Personal practice
Skill level: Professional
Frequently Asked Questions
What does B-Stock mean for this speaker?
B-Stock indicates the unit is fully functional and meets all performance specifications, but may have minor cosmetic imperfections or packaging wear. The acoustic and electrical performance is identical to new stock.
What is RBI technology and why does it matter?
RBI (Radiation Boundary Integrator) is a patent-pending waveguide adapted from JBL's VERTEC line arrays that minimizes phase distortion and acoustic dead zones in ceiling installations. It provides controlled, even projection across a 120° coverage angle without the beaming and acoustic nulls typical of conventional pendant speakers.
Is this speaker suitable for live performance venues?
Yes—the Control 65P/T-WH is rated for live performance applications. It delivers 105 dB continuous SPL (111 dB peak) and handles 75 Watts continuous (150W program) with 300W peak power, making it suitable for distributed ceiling coverage in mid-sized venues and performance spaces.
What wiring and transformer options are included?
The speaker includes a 60W multi-tap 70V/100V transformer with six selectable power taps (60W, 30W, 15W, 7.5W), plus two removable locking euro-block connectors for flexible installation in commercial audio systems. The 8-ohm rated impedance supports both low-impedance and transformer-based wiring schemes.
How does the coaxial driver design affect sound quality?
The coaxial configuration—with the 130 mm LF driver and 20 mm HF tweeter time-aligned on the same axis—ensures phase coherence and minimal comb-filtering across the frequency range. This delivers articulate midrange and smooth high-frequency extension without the phase issues common in non-coaxial designs.
