JBL Control 65P/T-WH 5.25" PREMIUM RBI PENDANT SPK W RBI, WHT

JBL Control 65P/T-WH 5.25" Premium RBI Pendant Speaker with RBI, White

The Control 65P/T-WH is a compact coaxial pendant speaker engineered for overhead studio monitoring and distributed recording environments. Its lightweight construction and patent-pending Radiation Boundary Integrator (RBI) technology deliver focused, controlled acoustic projection without the beaming and phase issues typical of conventional ceiling speakers. The white finish blends into any studio ceiling infrastructure while maintaining professional audio fidelity for critical listening and mixing applications.

Acoustic Performance & Coverage

This speaker produces 86 dB nominal sensitivity with a rated maximum SPL of 105 dB continuous (111 dB peak), delivering articulate transient detail and balanced frequency response across your recording chain. The 120° nominal coverage angle ensures even sound distribution throughout mid-sized control rooms and multi-room facilities, while RBI waveguide technology — adapted from JBL's VERTEC line arrays — minimizes phase distortion and acoustic dead zones common in overhead pendant installations, preserving mix accuracy and stereo imaging.

Design & Build Quality

The 130 mm coaxial driver arrangement pairs a polypropylene-coated LF cone with a neodymium 20 mm textile soft-dome HF driver featuring ferro-fluid cooling for extended reliability during long studio sessions. Robust High Impact PolyStyrene (HIPS) construction with steel and rubber components ensures durability and vibration isolation in studio installations, while the compact 234 mm diameter footprint and 3.7 kg weight simplify integration into existing ceiling-mounted monitoring systems.

Key Features

• 130 mm (5.25-inch) low-frequency driver with polypropylene-coated cone and copper voice coil
• 20 mm (3/4-inch) textile soft-dome tweeter with neodymium magnet and ferro-fluid cooling
• Coaxially mounted driver configuration for time-aligned output
• Patent-pending Radiation Boundary Integrator (RBI) with 200 mm diameter waveguide
• 75 Watts continuous pink noise (150 Watts program), 300 Watts peak power handling
• 8-ohm rated impedance
• 60W multi-tap 70V/100V transformer with six selectable taps (60W, 30W, 15W, 7.5W)
• Frequency response: 55 Hz – 20 kHz (-10 dB); 78 Hz – 18 kHz (±3 dB)
• Maximum SPL: 105 dB continuous, 111 dB peak at 1 meter
• 120° nominal coverage angle with ±20°/-10° characteristics
• Two removable locking euro-block connectors with screwdown terminals
• Compact 234 mm diameter, 259 mm height; 3.7 kg weight

The Control 65P/T-WH combines discrete overhead integration with advanced acoustical engineering, making it the choice for recording facilities where consistent phase coherence and transparent monitoring are equally critical to capture and mix quality.
