What guitar types can this pickup fit?

The SM-2N is designed as a mini-humbucker drop-in replacement for guitars with mini-humbucker routed cavities and Firebird-style mounting compatibility. It uses standard 3-48 humbucker mounting screws, so verify your guitar's routing before purchasing.

Is the 4-conductor cable important?

Yes—the 4-conductor cable allows you to configure the pickup in series, parallel, or split-coil wiring modes, giving you tonal flexibility that single-conductor designs cannot offer. This is especially useful for studio work and players who like options.

What tone should I expect in a neck position?

Expect articulate midrange with balanced warmth and definition, excellent note separation, and harmonic complexity suited to jazz voicings and rock applications. The 9 kHz resonant peak and 5/6/6 EQ voicing ensure clean response without mud or feedback, whether played clean or driven.

Will this work for metal or thrash?

This pickup is optimized for jazz, rock, and blues and is not recommended for metal or thrash, where higher output and aggressive midrange boosting are typically preferred.

Why is vacuum wax potting mentioned?

Vacuum wax potting seals the pickup's coils to eliminate microphonic squealing and feedback, ensuring reliable, squeal-free operation on stage and in the studio regardless of gain or volume levels.

Seymour Duncan SM-2N Custom Mini Humbucker 4-Conductor Neck Pickup

The SM-2N captures articulate, balanced midrange character that sits clearly in dense mixes without muddying adjacent frequencies. This ceramic-magnet design pairs warmth with definition, tracking cleanly through both clean and driven recording passes without excess mud or feedback. The compact form factor and vacuum wax potting make it a reliable drop-in solution for engineers seeking refined neck-position clarity that translates through the mix.

Tone & Output for Recording

An 8.52 kΩ DC resistance paired with a 9 kHz resonant peak positions this pickup in articulate midrange territory, favoring note separation and harmonic complexity during tracking and layering. The EQ balance of 5/6/6 (Bass/Mid/Treble) emphasizes the midrange without sacrificing low-end presence or high-end articulation, making it equally effective for jazz voicings and rock applications in the same session.

Design & Installation

Built with Ceramic Bar magnets and vacuum wax potted construction to eliminate microphonic squealing during recording, this neck pickup integrates seamlessly into mini-humbucker routed cavities. The Firebird-style mounting ring with 3-48 humbucker mounting screw provides secure, standard installation, while the 4-conductor cable enables series, parallel, or split-coil wiring options for in-the-box flexibility and experimentation.

Key Features

4-conductor cable for flexible wiring configurations
DC Resistance: 8.52 kΩ (Neck)
Resonant Peak: 9 kHz
Ceramic Bar magnet construction
EQ voicing: 5 Bass / 6 Mid / 6 Treble
Vacuum wax potted for squeal-free operation
Mini-humbucker drop-in replacement with Firebird-style mounting ring
3-48 humbucker mounting screw
6-string configuration
Manufactured in the United States

The SM-2N combines articulate midrange response with proven Seymour Duncan reliability, delivering transparent neck-position tone that holds its own in multitrack sessions and supports versatile production across genres.

Condition	New
Country of Manufacture	United States
