Martin MAC One in Cardboard

Martin MAC One in Cardboard

The Martin MAC One is a compact, lightweight moving head fixture engineered for studio installations and small-to-medium venue recording applications where reliable output and silent operation are critical. Its ultra-compact form factor makes it easy to position in tight spaces, while the integrated Fresnel lens delivers precise beam control for consistent key and fill lighting during video production and live-to-tape sessions. Built for producers and engineers who demand consistent performance in controlled recording environments.

Optical Performance & Output

This fixture delivers 2,500 lumens with an impressive narrow beam intensity of 375,000 cd, making it capable of cutting through ambient light and establishing clean key light separation. The integrated Fresnel lens with 4–27° zoom range provides flexible beam shaping from tight spots to wider washes, adapting quickly between setup configurations, while the 120 W custom-developed RGBL LED engine ensures color accuracy across the full spectrum with 21.4 lm/W efficacy for consistent results across multiple takes.

Design & Thermal Characteristics

The high-impact flame-retardant thermoplastic housing with IP20 protection rating survives the demands of active studio environments and location recording. Thermal management is exceptional—achieving only 23 dB(A) in theater and broadcast mode ensures this fixture runs virtually silent, critical for production workflows where fan noise would contaminate audio or disrupt recording sessions.

Key Features

• 2,500 lumens output with 375,000 cd narrow beam intensity
• 120 W RGBL LED light engine with 24 RGB effect LEDs in lens
• Integrated Fresnel lens with 4–27° zoom range
• DMX, Art-Net, sACN, and Martin P3 control compatibility
• Ultra-quiet operation at 23 dB(A) in theater/broadcast mode
• Weight: 4.4 kg (9.7 lbs) with compact 254 × 297 × 220 mm form factor
• IP20-rated high-impact flame-retardant housing
• Flexible power compatibility: 100V–240V operation
• FSC-certified cardboard packaging (inner and outer)
• 21.4 lm/W maximum efficacy

The MAC One combines exceptional optical performance with genuine portability and silent operation, making it an intelligent choice for video production, live-to-tape sessions, and installations where space and noise constraints directly impact recording quality.
