Martin MAC Aura XB White in cardboard

Martin MAC Aura XB White

The MAC Aura XB is a compact moving head fixture that balances professional output with genuine portability. At 6.5 kg and measuring just 302 mm across, this white cardboard version delivers serious lighting firepower without demanding dedicated truck space, making it equally at home in small theater rigs, touring productions, and permanent installations where real estate matters.

Light Output & Color Mixing

The 19× 15W RGBW LED array combined with 30× 0.3W RGB aura LEDs generates 6,000 lumens in wide mode and 4,300 lumens in narrow, with a peak intensity of 220,000 cd from the narrow beam. Independent RGBW beam mixing and RGB aura color mixing provide seamless color transitions, while variable CTO control (10,000–2,500 K) handles everything from deep amber washes to daylight-balanced washes without color wheels.

Control & Optics

Full DMX512-A compliance with selectable 14 or 25 DMX channels and RDM support integrates seamlessly into any rig, while the 9.0° to 59.1° zoom range adapts to tight spots and broad washes. Ultra-fast refresh rates—1,200 Hz for beam and 4,395 Hz for aura—eliminate flicker in video and high-speed camera work.

Key Features

• 19× 15W RGBW LED beam array with 30× 0.3W RGB aura LEDs
• 6,000 lumens (wide) / 4,300 lumens (narrow) luminous output
• Peak luminous intensity: 220,000 cd (narrow beam)
• LED lifetime: 50,000 hours to >70% luminous output
• RGBW beam color mixing with RGB aura color mixing
• Variable CTO color temperature control: 10,000–2,500 K
• Zoom range: 9.0° to 59.1°
• DMX512-A control with 14/25 selectable DMX channels and RDM compliance
• Beam refresh rate: 1,200 Hz; Aura refresh rate: 4,395 Hz
• High-impact thermoplastic housing, flame-retardant to UL 94 5VA
• Compact dimensions: 302 mm width, 360 mm height; 6.5 kg weight
• Electrical efficiency across 100–240V AC mains (1.6–3.8 A typical)

The MAC Aura XB delivers moving head performance that punches well above its size class and power draw, backed by Martin's standard build quality and a proven LED architecture.
