JBL VRX932LA-1WH 12" Two-Way Line Array Loudspeaker System
Description
JBL VRX932LA-1WH 12" Two-Way Line Array Loudspeaker System
The VRX932LA-1WH is engineered for studio monitoring and small-venue recording applications, delivering transparent output with impressive headroom and articulate midrange definition that reveals mix decisions with precision. The 12-inch woofer paired with three high-frequency compression drivers produces a responsive, dynamic character that remains tight and controlled across music production, voiceover, and podcast recording workflows. The modular line array design allows stacking and angling of multiple units for optimal acoustic coverage in tracking rooms, live recording spaces, and small venue documentation sessions.
Acoustic Performance & Monitoring Capabilities
This system achieves a 130 dB SPL peak in passive mode with extended frequency response from 57 Hz to 20 kHz (–10 dB), ensuring deep bass reproduction and crystalline high-frequency detail for accurate mix translation. The 100-degree horizontal and 15-degree vertical coverage angles provide precise acoustic placement ideal for line array configurations in recording spaces, while the 1.2 kHz crossover frequency ensures seamless integration between the woofer and compression drivers for flat on-axis response.
Driver Design & Enclosure Construction
The 2262H 305 mm (12 in) Differential Drive woofer features dual voice-coils, dual magnetic gaps, and a neodymium magnet for controlled, articulate bass reproduction suitable for tracking and mixing sessions. Three 2408J compression drivers with 38 mm voice-coils and neodymium magnets deliver clarity and efficiency in the upper midrange and high frequencies, all housed in a robust 18 mm, 11-ply birch plywood enclosure finished in white Duraflex with a power-coated steel grille.
Key Features
- 1 x JBL 2262H 305 mm (12 in) Differential Drive woofer with neodymium magnet, dual voice-coils, and dual magnetic gaps
- 3 x JBL 2408J compression drivers with 38 mm voice-coil and neodymium magnet
- Nominal impedance: 8 Ohms (passive); selectable bi-amp LF 8 Ohms / HF 8 Ohms
- Power rating: 800W / 1600W / 3200W (Continuous / Program / Peak, passive mode)
- System sensitivity: 95 dB SPL passive mode (1 watt @ 1 meter); LF 95 dB / HF 114 dB (bi-amp mode)
- Maximum SPL: 130 dB peak (passive); LF 130 dB / HF 139 dB (bi-amp mode)
- Frequency response: 75 Hz – 20 kHz (±3 dB); 57 Hz – 20 kHz (–10 dB)
- Coverage angles: 100 degrees horizontal × 15 degrees vertical
- Crossover frequency: 1.2 kHz
- Dual Neutrik Speakon NL-4 input connectors
- 18 mm, 11-ply birch plywood enclosure
- Dimensions: 13.5" H × 23.5" W × 14.8" D; Weight: 48 lbs
The VRX932LA-1WH combines professional accuracy and reliability with the transparent sound reproduction that supports critical listening and precise mix decisions in recording environments.
More Information
| Condition | New |
|---|---|
| Country of Manufacture | Mexico |
Reviews
At a Glance
The JBL VRX932LA-1WH is a stage-focused line array speaker built for live capture and reinforcement, not studio monitoring—it excels at delivering uncolored, articulate output across large venues and festival grounds. Its extended frequency response (57 Hz–20 kHz), three compression drivers, and 8-ohm passive impedance make it ideal for multi-unit PA deployments where consistent, predictable coverage is essential. This is the right choice if you're mixing live sound or recording direct from a venue PA that demands professional SPL handling and tonal consistency.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Tour Sound
- ✓ Festival PA
- ✓ Venue Reinforcement
Not the best pick for
- – Home listening
- – Studio monitoring
- – Personal practice
Frequently Asked Questions
Can I use this speaker in passive mode, or do I need powered amplification?
The VRX932LA-1WH operates in passive mode (800W continuous / 1600W program / 3200W peak) and requires external amplification. It also supports bi-amp operation (selectable 8 Ohm LF / 8 Ohm HF), allowing you to run dedicated amps for the woofer and drivers separately for greater control and SPL headroom.
How do I configure multiple units for larger venues?
The modular line array design allows you to stack and angle multiple VRX932LA-1WH units for optimal coverage across different audience areas. Each unit features 100-degree horizontal and 15-degree vertical coverage angles, and dual Neutrik Speakon NL-4 connectors for easy daisy-chaining into your amp chain.
What frequency range and SPL should I expect from this speaker?
Frequency response is 75 Hz–20 kHz (±3 dB) with extended response down to 57 Hz (–10 dB) for deep bass. Peak SPL is 130 dB in passive mode; bi-amp mode reaches 130 dB LF and 139 dB HF, giving you headroom for high-energy live applications.
What's inside this enclosure, and how durable is it for touring?
The cabinet is built from 18 mm, 11-ply birch plywood with a white Duraflex finish and power-coated steel grille—designed to survive road use and outdoor conditions. Inside are one 12-inch dual voice-coil Differential Drive woofer with neodymium magnet and three compression drivers with 38 mm voice-coils, all tuned for responsive, articulate sound.
How does the VRX932LA-1WH compare to the Electro-Voice ETX-12P or QSC KLA12?
The JBL delivers competitive 130 dB peak SPL with three compression drivers and tight, controlled bass articulation. It shares professional-grade line array performance with comparable models but stands out for its dual voice-coil woofer design and proven reliability in touring and festival environments; compare specs and demo coverage patterns to match your venue size and genre.
