JBL VLA-C265-BK Two-Way Horn-Loaded Line Array System

The VLA-C265-BK is a compact, rigging-ready line array element engineered for precise frequency management and controlled directional output in studio monitoring and installed sound applications. Its integrated rigging system and modest 848mm width make it practical to configure while maintaining the directional control and output capability expected from professional horn-loaded systems. The weatherproof fiberglass construction and IP-55 rating protect the drivers and electronics in demanding studio environments—indoor and outdoor.

Acoustic Performance

This unit combines three D2415 compression drivers with dual 10" Differential Drive woofers to deliver 131 dB continuous SPL at 1 meter, with usable response from 85 Hz to 19 kHz (–10 dB limits). The 65° horizontal coverage pattern provides consistent, predictable directivity across working distances, while the horn-loaded design ensures efficient power handling and controlled directional output that integrates cleanly into multi-element arrays or hybrid monitoring setups.

Construction & Integration

Multi-layer reinforced fiberglass and steel end-panels protect the internal drivers, while the IP-55 rated zinc-plated perforated steel grille with waterproof rail system and hydrophobic mesh backing withstands splashing and dust ingress. The integrated rigging system supports five inter-enclosure angles (1.5°, 2.4°, 3.8°, 6.0°, 9.5°) for precise array tuning and acoustic alignment across the listening field.

Key Features

• Frequency range (–10 dB): 85 Hz – 19 kHz
• Frequency response (±3 dB): 108 Hz – 16.5 kHz
• Maximum SPL: 131 dB continuous at 1 meter
• Three D2415 compression drivers with 1.5" annular diaphragms and neodymium motors
• Dual 2261 10" Differential Drive woofers with 3" voice coils
• 65° horizontal coverage pattern
• IP-55 rating (dust protected, water-jet resistant)
• Multi-layer reinforced fiberglass and steel end-panel construction
• Integrated rigging system with adjustable inter-enclosure angles
• Dimensions: 381 × 848 × 460 mm (15.0 × 33.4 × 18.1 in)
• CE-compliant barrier strip terminals accepting up to 10 AWG wire
• Zinc-plated perforated steel grille with waterproof rail system and hydrophobic mesh

The VLA-C265-BK delivers professional line array performance in a compact, road-tested platform with the acoustic precision and rigging flexibility required for critical monitoring and permanent installations.
