JBL VLA-C2100-BK Two-way horn-loaded line array system. 100° horizonta
Description
JBL VLA-C2100-BK Two-Way Horn-Loaded Line Array System
The VLA-C2100-BK is a compact, high-output line array element engineered for studio reference, broadcast monitoring, and live recording applications demanding consistent coverage and transparent acoustic performance. Its horn-loaded design delivers controlled directivity and efficient acoustic output with phase-coherent crossover behavior, making it ideal for tracking sessions, mixing suites, and remote recording environments where accuracy and reliability matter.
Coverage & Acoustic Design
The 100° horizontal horn coverage pattern ensures uniform sound distribution across the control room or tracking space with minimal off-axis coloration, critical for accurate mixing and monitoring decisions. The dual-driver low-frequency section paired with three high-frequency drivers optimizes the phase relationship between frequency bands, resulting in smooth crossover performance and articulate vocal and instrument reproduction that translates reliably across playback systems.
Build & Environmental Rating
Multi-layer reinforced fiberglass construction combined with zinc-plated, powder-coated 14-gauge steel grilles and hydrophobic mesh underlayers provides extended durability in studio and mobile recording environments. The IP-55 rating per IEC529 certifies protection against dust ingress and direct water jets, making this system suitable for permanent studio installation, outdoor recording sessions, or mobile production rigs.
Key Features
- Dual 2261 10" Differential Drive 3" voice coil low-frequency drivers
- Three D2415 high-frequency drivers with 1.5" annular diaphragms and neodymium motors
- 100° horizontal horn-loaded coverage pattern
- Bi-amp or passive operation with field-switchable configuration
- Multi-layer reinforced fiberglass and steel end-panel construction
- Zinc-plated, powder-coated 14-gauge perforated steel grilles
- Acoustically transparent black grill cloth with hydrophobic mesh underlayer
- Waterproof rail system for secure array rigging
- IP-55 environmental rating (dust and water jet protected)
- CE-compliant covered barrier strip terminals accepting up to 10 AWG wire or 0.375" spade lugs
- Dimensions: 381 x 848 x 460 mm (H x W x D)
- Black finish
This system combines professional-grade component drivers, proven line array geometry, and rugged environmental protection to deliver reliable monitoring and recording performance across studio sessions, live tracking, and location recording applications.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL VLA-C2100-BK is a professional line array element designed for live sound capture and installed systems, not studio recording or mixing. Its horn-loaded geometry and tuned driver complement provide controlled directivity and efficient output ideal for live reinforcement, broadcast, and venue installation where consistent acoustic behavior across a space is critical. This is a touring and permanent-install tool, not a tracking or mixing tool.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Festival Sound
- ✓ Installed Sound Systems
Not the best pick for
- – Home Recording
- – Studio Sessions
- – Small Venue Intimacy
Skill level: Professional
Frequently Asked Questions
What does IP-55 rating mean for outdoor use?
IP-55 certifies protection against dust ingress and direct water jets, making the system safe for permanent outdoor installation or mobile rental applications in rain and wet conditions. The hydrophobic mesh underlayer, zinc-plated steel grilles, and waterproof rail system support extended durability in demanding environmental contexts.
Can this system be used passively or does it require amplification?
The VLA-C2100-BK supports both bi-amp and passive operation with field-switchable configuration, so it can work with either dedicated amplifiers per driver type or a single passive amplifier depending on your rig setup.
What coverage pattern does the 100° horizontal horn provide?
The 100° horizontal horn-loaded design ensures consistent sound distribution across the listening area with minimal off-axis coloration, making it ideal for wide-format venue coverage in touring and installed sound applications.
What drivers are inside and how do they work together?
The system pairs dual 2261 10" Differential Drive low-frequency drivers (3" voice coil) with three D2415 high-frequency drivers (1.5" annular diaphragms, neodymium motors) optimized for smooth crossover performance and articulate vocal and instrument reproduction.
How is this different from a passive or powered monitor wedge?
The VLA-C2100-BK is a line array element—a compact, stackable module designed to be flown or stacked in multiples to cover large venues and outdoor festivals with consistent, controlled directivity. It is a main PA or installed system component, not a stage monitor or personal wedge.
