JBL PD6200/66-WH Two-way mid-high horn-loaded loudspeaker (white)
- Brand new in original box
- Full JBL manufacturer's warranty
- Free shipping in the continental US
In stock
Only 1 left
- SKU
- PD6200/66-WH
Description
JBL PD6200/66-WH Two-Way Mid-High Horn-Loaded Loudspeaker
The PD6200/66-WH is a compact, rotatable mid-high speaker system engineered for flexible deployment in studio monitoring and mixing environments. Its horn-loaded design delivers focused, controlled directivity with the efficiency needed for consistent acoustic behavior in control rooms ranging from compact project studios to larger tracking and mixing spaces.
Acoustic Design & Coverage
This system employs large-format PT™ Progressive Transition™ waveguides paired with an 8" CMCD cone midrange compression driver and 1.5" HF compression driver with neodymium magnet to achieve predictable 60 × 60° coverage across the 200 Hz to 18 kHz frequency range. The rotatable waveguide design allows quick orientation switching from horizontal to vertical without cabinet modification, adapting to both desktop and wall-mounted monitoring applications for precise stereo imaging and mix translation.
Build & Studio Integration
Constructed from durable birch plywood with DuraFlex finish, the PD6200 resists vibration coupling and environmental stress in the studio. M10 threaded rigging attachments provide secure mounting options for stands or wall installation, while NL4 speakON and barrier strip inputs support both bi-amp and passive operation modes, simplifying integration into existing mixing console routing and DSP-based monitoring setups.
Key Features
- 8" CMCD cone midrange compression driver with dual voice coil design
- 1.5" exit HF compression driver with large-format neodymium magnet
- 60 × 60° coverage pattern for controlled directivity
- Frequency response: 200 Hz to 18 kHz
- Large PT™ Progressive Transition™ waveguides
- Rotatable waveguides for horizontal or vertical cabinet orientation
- Birch plywood construction with DuraFlex finish
- M10 threaded rigging attachments for suspension mounting
- NL4 speakON and barrier strip inputs
- Bi-amp and passive operating modes
This mid-high system delivers the precision, consistency, and operational flexibility required in professional recording and mixing applications.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The PD6200/66-WH is a professional mid-high compression driver system designed for large-format mixing and monitoring, not primary studio tracking or mixing. Its horn-loaded efficiency and controlled 60×60° directivity make it valuable in mastering suites or live-to-studio hybrid setups where you need predictable, artifact-free mid-high reproduction and SPL headroom. It excels in applications where studio-grade monitoring must coexist with stage-duty reliability.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Theater/Install
- ✓ Medium-to-large Venues
Not the best pick for
- – Home Studio
- – Small Bedroom Practice
Skill level: Professional
Frequently Asked Questions
What does the rotatable waveguide design do?
The waveguide rotates between horizontal and vertical orientation without requiring cabinet modification, letting you aim the 60×60° coverage pattern to match your stage layout or overhead rig instantly.
Can I use this in both passive and bi-amped setups?
Yes. The PD6200/66-WH supports both passive operation and bi-amp modes via dual voice coil design, with NL4 speakON and barrier strip inputs for flexible integration into existing touring or venue systems.
What is the frequency range and coverage pattern?
Frequency response spans 200 Hz to 18 kHz with a tight 60×60° coverage pattern, delivered through an 8-inch CMCD compression driver for midrange and 1.5-inch neodymium HF driver for articulate high-end response.
How does this stand up to touring and outdoor use?
The cabinet is built from durable birch plywood with DuraFlex finish and includes M10 threaded rigging attachments, designed to withstand road wear, environmental stress, and secure suspension mounting in demanding venues and installations.
How does this compare to other pro mid-high speakers?
The PD6200/66-WH sits alongside models like the JBL PD6200/64, d&b audiotechnik M4, and EAW QX5259 in the touring and install mid-high category; its rotatable design and large PT Progressive Transition waveguides offer operational flexibility and predictable coverage that touring rigs value.
