JBL PD595 15" 2-way full-range, 90 X 50

JBL PD595 15" 2-Way Full-Range Speaker System

The JBL PD595 is a versatile two-way loudspeaker engineered for professional recording, mixing, and monitoring applications, offering the combination of high sensitivity and controlled directivity that studio engineers and room designers demand. Its 90° × 50° coverage pattern and rotatable waveguide make it equally effective as a primary monitor, near-field reference, or secondary system in mid-sized control rooms, tracking spaces, and mastering suites. The robust construction and switchable bi-amp/passive modes provide flexibility across a range of studio deployment scenarios.

Audio Performance & Tonal Character

The PD595 delivers a 104 dB SPL sensitivity at 1W/1m in passive mode, with peak output reaching 139 dB in bi-amp configuration—sufficient headroom for critical monitoring and session work without excessive amplifier demand. The 90 Hz to 16 kHz (±3 dB) frequency response prioritizes the critical midrange and presence peak essential for tracking and mixing decisions, while the 1.3 kHz crossover integrates the 2031H 380 mm (15") woofer and 2432H compression driver for smooth, coherent sound reproduction across the operating band.

Design & Studio Integration

The speaker features barrier strip input connectivity, 8-ohm nominal impedance, and 22 M10 threaded suspension points for flexible positioning and permanent mounting in studio environments. Its rotatable waveguide accommodates both vertical and horizontal orientations for optimal console placement, and the compact footprint—783.59 mm H × 789.94 mm W × 669.80 mm D—fits efficiently into control rooms and tracking spaces without sacrificing acoustic performance.

Key Features

• 2031H 380 mm (15") low-frequency driver with high sensitivity and low power compression
• 2432H compression driver with 38 mm (1.5") exit and 75 mm (3") voice coil with neodymium magnet and aluminum diaphragm
• Frequency range: 50 Hz to 20 kHz (−10 dB)
• Frequency response: 90 Hz to 16 kHz (±3 dB)
• Coverage pattern: 90° × 50°
• System sensitivity: 104 dB SPL (1W @ 1m, passive mode)
• Maximum SPL: 133 dB continuous / 139 dB peak (bi-amp mode)
• Nominal impedance: 8 ohms
• Power rating: 500W at 2 hrs, 300W at 100 hrs (passive mode)
• Crossover frequency: 1.3 kHz with bi-amp/passive switchable modes
• 22 M10 threaded suspension points for rigging and mounting
• Rotatable waveguide for vertical or horizontal orientation

The PD595 combines proven JBL engineering with the output capability and pattern control required for dependable mid-sized studio monitoring and recording applications.
