JBL PD566-WH 15" 2-Way Full-Range Speaker

The JBL PD566-WH is a compact, high-output two-way system engineered for consistent coverage and versatile studio deployment. Its trapezoidal cabinet and 20-point suspension design deliver balanced acoustic performance across the listening plane, while the sophisticated passive crossover network ensures seamless integration between the 15" woofer and compression driver. This white-finished unit combines professional durability with practical flexibility for both fixed monitoring setups and portable tracking applications.

Sonic Character & Frequency Response

The dual-driver configuration pairs a 2031H 15" woofer with 3" voice coil (106 dB sensitivity) and JBL 2432H 1.5" compression driver with 3" voice coil (114 dB sensitivity) to deliver uniform response across the mid and high frequency spectrum. The PT-H66HF-1 300 x 300 mm waveguide ensures a controlled 60 x 60 degree dispersion pattern, maintaining consistent frequency response throughout the monitoring environment without proximity peaks or shadowed zones—critical for accurate mixing and tracking decisions.

Cabinet Engineering & Rigging

The cabinet is constructed from 18 mm, 11-ply exterior grade Finnish birch plywood in a trapezoidal shape with 10-degree side angles, providing structural rigidity and precise acoustic behavior. The DuraFlex™ finish in white resists wear and UV degradation, while M10 threaded suspension hardware at 20 points (5 top, 5 bottom, 4 each side, 2 rear) allows secure mounting and flexible deployment options for studio, rehearsal, or mobile recording rigs.

Key Features

• 2031H 15" woofer with 75 mm (3 in) voice coil, 8 ohms nominal impedance
• JBL 2432H 38 mm (1.5 in) compression driver with 75 mm (3 in) voice coil, 8 ohms nominal impedance
• Low frequency sensitivity: 106 dB (1W, 1m, avg 300Hz–1.3kHz)
• High frequency sensitivity: 114 dB (1W @ 1m, avg 1.5k–5kHz)
• PT-H66HF-1 300 x 300 mm (12 x 12 in) waveguide with 60 x 60 degree coverage pattern
• Trapezoidal cabinet with 10-degree side angles, 18 mm 11-ply Finnish birch plywood construction
• DuraFlex™ finish, white (-WH) variant
• 20-point M10 threaded suspension attachment (5 top, 5 bottom, 4 each side, 2 rear)
• CE-compliant covered barrier strip input connectors accepting up to 5.2 sq mm (10 AWG) wire or 9 mm spade lugs
• Switchable bi-amp and passive crossover modes with steep-slope network
• Dimensions: 782.0 x 783.0 x 670.0 mm (30.8 x 30.8 x 26.4 in, vertical orientation)

The PD566-WH delivers the output and pattern control demanded by studio tracking, mixing, and installed monitoring applications, backed by JBL's professional-grade component selection and cabinet engineering.
