JBL NCSM28-U-US
Description
JBL NCSM28-U-US Networked Control and Status Module
The NCSM28-U-US is a professional-grade control and mixing interface built for studio networking and distributed recording setups. This compact 1U rack unit delivers transparent audio processing with minimal latency, making it an essential component for multi-room recording facilities, networked studio environments, and distributed audio workflows that demand reliability and clean signal management.
Audio Performance & Signal Integrity
The unit maintains exceptional audio fidelity across the entire audible spectrum with frequency response of 20–20,000 Hz ±1 dB and total harmonic distortion of just 0.05%. A signal-to-noise ratio exceeding 90 dB ensures clean audio paths for tracking and mixing, while ±10 dB tone controls at 100 Hz and 10,000 Hz provide practical EQ adjustment for source matching and creative processing in the mix.
Connectivity & Studio Integration
Eight independent inputs and two outputs accommodate flexible routing configurations using Euroblock connectors for balanced mic/line connections, unbalanced RCA inputs, and RJ45 connectors compatible with CSR-V in-wall volume controls. The fanless design and minimal 10W power consumption make this unit ideal for rack-mounted studios and recording spaces where acoustic silence and clean monitoring signals are essential.
Key Features
- 8 inputs, 2 outputs with independent control
- Frequency response: 20–20,000 Hz ±1 dB
- Total harmonic distortion: 0.05% typical
- Signal-to-noise ratio: >90 dB
- Input impedance: Mic 400Ω, Line 20kΩ, RCA 50kΩ
- Dual tone controls: Bass ±10 dB at 100 Hz, Treble ±10 dB at 10,000 Hz
- Line output level: 5.0 V RMS into 10 kOhms
- Euroblock, RCA, and RJ45 connector options
- Phantom power supply: +27 VDC
- Universal power supply: 100–240 VAC, 50/60 Hz
- Fanless 1U full-rack form factor: 17.2" × 11.9" × 1.7"
- RoHS compliant and GreenEdge certified
The NCSM28-U-US combines straightforward interface design with transparent audio processing, making it a dependable control point for professional recording and monitoring workflows.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL NCSM28-U-US is a professional control and mixing interface designed for networked and installed audio environments, not music production or recording workflows. It offers transparent signal integrity with a 90+ dB signal-to-noise ratio, practical bass and treble tone controls for room matching, and flexible balanced/unbalanced connectivity that serves distributed audio networks and conferencing systems.
Who This Is For
Great for
- ✓ installed audio systems
- ✓ conference systems
- ✓ distributed audio networks
- ✓ commercial installations
Not the best pick for
- – live performance mixing
- – music production
- – portable applications
Skill level: Professional
Frequently Asked Questions
What is this unit designed to do?
The NCSM28-U-US is a networked control and mixing module for installed audio systems, conference rooms, and distributed commercial audio networks. It provides eight independent inputs, two outputs, transparent audio processing with minimal latency, and practical EQ controls for room compensation—it is not designed for live performance mixing or music production.
What connectivity options does it have?
The unit offers eight inputs and two outputs with Euroblock connectors for balanced mic/line connections, unbalanced RCA inputs, and RJ45 connectors compatible with CSR-V in-wall volume controls, supporting flexible routing for installed systems.
What are the audio specs and signal quality?
Frequency response is 20–20,000 Hz ±1 dB with 0.05% THD and a signal-to-noise ratio exceeding 90 dB, ensuring clean audio paths. Input impedance varies by type: microphone at 400Ω, line at 20kΩ, and RCA at 50kΩ.
Is this unit suitable for retrofit and quiet installations?
Yes—the fanless design and minimal 10W power consumption make it ideal for retrofit installations and spaces where acoustic silence is required, plus it operates on universal 100–240 VAC power.
What EQ adjustment does it provide?
Dual tone controls offer ±10 dB adjustment at 100 Hz (bass) and 10,000 Hz (treble), allowing practical room compensation and source matching in installed audio environments.
