JBL NCSM14-U-US
Description
JBL NCSM14-U-US Compact Audio Mixer
The NCSM14-U-US is a compact, fanless mixer engineered for fixed recording installations and networked studio environments. Its shallow 1U half-rack footprint and lightweight construction fit seamlessly into control rooms, live tracking setups, and distributed recording spaces where silent operation and reliable signal management are essential.
Design & Build Quality
Built as a fanless unit measuring just 8.6" W × 11.9" D × 1.7" H and weighing 4.41 lbs, this mixer integrates into existing studio rigs without acoustic noise or thermal concerns. The black finish and minimal footprint keep it visually neutral in any recording environment, while the universal power supply (AC 100–240 VAC, 50/60 Hz) enables portable and multi-room studio configurations.
Audio Performance & Connectivity
The 4 input / 1 output configuration provides clean signal routing with frequency response of 20 Hz to 20 kHz ±1 dB, preserving full-spectrum fidelity for mixing and monitoring. Input flexibility includes Euroblock mic/line connectors, unbalanced RCA inputs, and RJ45 connections for JBLCSR-V in-wall volume controls, while 27 VDC phantom power supports condenser microphones and the 70 Hz high-pass filter switch removes unwanted low-frequency rumble during tracking and playback.
Key Features
- 4 inputs / 1 output configuration
- Frequency response: 20 Hz to 20 kHz ±1 dB
- Mic input sensitivity: 3 mVrms
- Line input sensitivity: 775 mVrms
- RCA input sensitivity: 300 mVrms
- 27 VDC phantom power for condenser microphones
- 70 Hz high-pass filter switch
- Euroblock mic/line inputs and output connectors
- Unbalanced RCA inputs for consumer audio sources
- RJ45 connectors for JBLCSR-V in-wall volume controls
- 1U half-rack, fanless design: 8.6" W × 11.9" D × 1.7" H
- Universal AC 100–240 VAC, 50/60 Hz power supply
The NCSM14-U-US delivers the straightforward mixing and control architecture that studio installations and recording workflows demand, backed by JBL's 3-year limited warranty.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL NCSM14-U-US is a compact 4-input mixer designed for fixed installations and background-music systems, not for recording or music production workflows. Its neutral, transparent frequency response and low-noise fanless operation suit session playback and routing in controlled environments, but the single-output design and limited channel count make it unsuitable for multitrack recording or studio mixing. Consider it only if you need a simple, silent utility mixer for fixed playback or monitoring in a studio facility.
Who This Is For
Great for
- ✓ Commercial installations
- ✓ Fixed audio systems
- ✓ Conference rooms
- ✓ Background music systems
Not the best pick for
- – Live sound touring
- – High-channel-count mixing
- – Music production
Skill level: Beginner · Intermediate
Frequently Asked Questions
What inputs and outputs does this mixer have?
The NCSM14-U-US provides 4 inputs and 1 output. Inputs include Euroblock mic/line connectors, unbalanced RCA inputs, and RJ45 connections for JBL in-wall volume controls; outputs are balanced Euroblock connectors.
Can I use condenser microphones with this mixer?
Yes. The mixer supplies 27 VDC phantom power to support condenser microphones on the Euroblock mic inputs.
Is this mixer suitable for live sound or touring?
No. The NCSM14-U-US is designed for fixed commercial installations like conference rooms and background music systems, not for live sound touring or high-channel-count mixing applications.
How much space does this mixer take up?
It measures 8.6 inches wide, 11.9 inches deep, and 1.7 inches tall (1U half-rack format) and weighs 4.41 lbs, making it ideal for wall-mounted or tight-space deployments.
Does the mixer have a cooling fan?
No. The NCSM14-US is fanless, meaning it operates silently with no ventilation noise—a key advantage for installations where acoustic quiet is essential.
