JBL JBL-GSF6-TN Ground-Stake Spkr, 6.5" Coax, Tan, 1 pc

JBL GSF6-TN Ground-Stake Speaker, 6.5" Coax, Tan

The JBL GSF6-TN is a rugged coaxial ground-stake speaker engineered for permanent outdoor installations where durability and consistent coverage matter. This tan-finished unit delivers full-range sound from a compact form factor, anchored securely via included ground stake and L-bracket hardware. Built to withstand harsh environmental conditions, it's a reliable choice for landscape audio, resort installations, and commercial outdoor venues.

Audio Performance & Coverage

The coaxial design pairs a 6.5" polypropylene-cone woofer with a 1" titanium dome tweeter to produce smooth response across 65 Hz to 20 kHz. Sensitivity of 87 dB and peak SPL rating of 110 dB (@1m) provide adequate output for mid-sized outdoor spaces; the 70-degree conical coverage pattern ensures even sound distribution across typical installation areas.

Construction & Environmental Durability

Housed in a polycarbonate and ABS enclosure with aluminum grille, the GSF6-TN carries IP66 rating for comprehensive water and dust resistance and meets MilSpec 810 environmental standards for humidity, salt spray, temperature extremes, and UV exposure. The 30W multi-tap transformer switches between 8Ω direct operation and 70V/100V distributed systems, accommodating flexible system designs.

Key Features

• 165 mm (6.5") polypropylene-cone woofer with 25 mm (1") aluminum voice coil former
• 25 mm (1.0") titanium dome tweeter with neodymium magnet and Kapton voice coil former
• 30W multi-tap transformer: 8Ω direct or 70V/100V distributed system switchable
• Frequency response: 65 Hz to 20 kHz
• Sensitivity: 87 dB (average 300 Hz–12 kHz)
• Maximum SPL: 110 dB peak (104 dB continuous @ 1m, 2 hr rating)
• 70-degree conical coverage pattern
• IP66 rating with MilSpec 810 environmental compliance (humidity, salt spray, temperature, UV)
• Polycarbonate/ABS enclosure with aluminum grille
• 8.2 kg (18.1 lbs) per speaker; includes ground stake bracket and L-bracket
• Bare wire terminals with dielectric-gel-filled wire nuts; 1 meter single-jack cable (2-wire, 18 AWG)

The GSF6-TN combines proven JBL coaxial engineering with heavy-duty outdoor construction, delivering dependable full-range coverage in permanent landscape and commercial installations.
