JBL CSS-H30-BK 30W Paging Horn with Transformer – Black

The CSS-H30-BK is a compact, weather-resistant paging horn engineered for consistent vocal clarity and reliable performance in studio monitoring and live recording applications. Its compact footprint and stainless steel U-bracket make it straightforward to mount in control rooms, tracking spaces, and isolation booths without requiring extensive installation infrastructure. The integrated transformer and multi-tap configuration eliminate the need for external equipment, delivering professional results straight out of the box.

Coverage & Audio Performance

This horn produces a 108 dB sensitivity at 1W (peaking at 112 dB at 1.4 kHz), capable of sustaining 123 dB continuous average SPL with 129 dB peak output. The 50° × 70° coverage pattern ensures even sound distribution across recording spaces while the built-in 350 Hz high-pass filter cuts through low-frequency rumble, keeping spoken word and vocal recordings intelligible in tracking sessions.

Power & Integration Flexibility

The UL-registered 30W multi-tap transformer accommodates both 70V and 100V system configurations with selectable taps at 30W, 15W, 7.5W, 3.8W, and 1.9W, plus an 8-ohm direct bypass mode for flexible integration into existing studio console sends and monitoring chains. The 12-inch pigtail with bare wire connection and watertight fitting entrance simplify studio wiring while the IP65-rated ABS enclosure withstands environmental variations in any recording facility.

Key Features

• 30W system power rating (120W peak) with UL-registered transformer
• 108 dB sensitivity (1W, 2.83V @ 1m, 1 kHz–6 kHz average); 112 dB at 1.4 kHz
• 123 dB continuous average SPL (129 dB peak); 127 dB continuous at 1.4 kHz (133 dB peak)
• Frequency response: 380 Hz – 6 kHz (–10 dB)
• 50° horizontal × 70° vertical coverage pattern
• Multi-tap transformer: 70V/100V compatible with 30W, 15W, 7.5W, 3.8W, and 1.9W settings plus 8-ohm bypass
• 1.5-inch passive full-range driver with phenolic diaphragm
• Built-in 350 Hz high-pass filter for enhanced speech clarity
• IP65-rated weather-resistant ABS enclosure with stainless steel mounting bracket
• Compact dimensions: 8.9" H × 11.2" W × 11.3" D (224 × 285 × 287 mm)
• 12-inch pigtail with bare wire connections and watertight fitting entrance
• Directivity Index: 12 at 2 kHz for controlled, focused sound projection

The CSS-H30-BK delivers reliable, high-output monitoring performance with transformer flexibility and durability built into a space-efficient design.
