JBL Control Hst-wh 5.25" Wide Coverage On-wall Speaker, Wht

JBL Control HST-WH 5.25" Wide Coverage On-wall Speaker, White

The Control HST-WH is a compact, professional-grade on-wall speaker engineered for studio monitoring applications, post-production suites, and distributed recording setups where even acoustic coverage and clean integration matter. Its shallow profile and included color-matched U-bracket allow seamless mounting without compromising room acoustics or workspace flow. The wide horizontal and vertical coverage pattern maintains consistent frequency response across the listening field, ideal for mix-referencing and tracking oversight.

Design & Installation

This speaker mounts flush to any wall with the included U-bracket, and its compact footprint (14.25 x 10.1 x 7.2 inches) fits cleanly into tight studio spaces without acoustic reflections or structural interference. The IP54 and Mil-Std-810 ratings provide protection against moisture, humidity, and environmental stress—valuable for vocal booths, live recording spaces, and rooms with variable climate control.

Audio Performance & Power

Built with a 5.25" CMMD woofer and dual fluid-cooled ¾" tweeters, the HST-WH delivers transparent midrange articulation and defined highs across a 50 Hz–20 kHz frequency response with 88 dB sensitivity. The integrated 60-watt 70V/100V multi-tap transformer and 100W system power rating (400W peak) support both line-level and high-impedance mixing console integrations, while 108 dB maximum SPL with peaks to 114 dB ensures headroom for active tracking and critical monitoring sessions in medium to large rooms.

Key Features

• 5.25" CMMD woofer with 25 mm voice coil
• Dual splayed ¾" fluid-cooled tweeters with CMMD-treated aluminum diaphragms
• 160 x 150° wide coverage pattern control
• 88 dB sensitivity (averaged 80 Hz–20 kHz)
• Maximum SPL: 108 dB direct into 8Ω, peaks to 114 dB
• 50 Hz–20 kHz frequency response
• Built-in 60W 70V/100V multi-tap transformer
• 100W system power rating (400W peak, 2 hrs per IEC)
• IP54 and Mil-Std-810 environmental ratings
• Removable locking 4-pin euro-block connector
• Aluminum grille with white finish
• Includes color-matched U-bracket for wall mounting

The Control HST-WH combines rugged environmental protection, straightforward installation, and reliable distributed-audio performance in a discreet on-wall package.
