JBL Control 126WT 6.5" In-wall Speaker with Transformer

The Control 126WT is a compact in-wall speaker engineered for studio monitoring installations, home theater setups, and distributed recording environments that demand consistent coverage and reliable performance. Its swivel tweeter and transformer-equipped design make it adaptable to varied room configurations and voltage requirements without requiring external equipment.

Recording & Monitoring Performance

This speaker delivers a frequency range of 38 Hz–20 kHz with 88 dB SPL sensitivity at 1W/1m, providing clear, articulate output across the full spectrum for accurate monitoring and critical listening. The 180° horizontal and 160° vertical coverage pattern (averaged 1 kHz–8 kHz) ensures even sound distribution throughout the listening area, while the high-slope crossover maintains natural midrange character essential for mix translation and vocal/dialogue clarity in your productions.

Studio Integration & System Setup

Built-in multi-tap 70V/100V transformer eliminates the need for external step-down equipment, simplifying integration into home-studio audio chains. The 8-ohm nominal impedance and 50W continuous power handling (100W program, 200W peak) connect seamlessly into both low-voltage and standard amplifier configurations. Screw-down Euroblock connectors provide secure, tool-friendly wiring suitable for professional studio installations.

Key Features

• 6.5" polymer-coated aluminum-cone woofer with pure butyl rubber surround
• 1" pure-titanium dome low diffraction tweeter with swivel aimability
• Frequency range: 38 Hz – 20 kHz
• Sensitivity: 88 dB SPL, 1W, 1m
• Coverage pattern: 180°H x 160°V (average 1 kHz – 8 kHz)
• Power handling: 50W continuous / 100W program / 200W peak
• Nominal impedance: 8 ohms
• Multi-tap transformer for 70V/100V systems
• Tweeter aimability: -10 degree adjustment
• Screw-down Euroblock-type connector
• Weight: 6.2 kg (13.5 lbs)
• High-slope crossover for natural midrange reproduction

The Control 126WT combines professional-grade drivers with practical installation features, making it a reliable choice for applications requiring consistent in-wall audio performance and accurate monitoring across your production workflow.
