JBL AW566-LS-BK 15" HI-PWR ALL-WEATHER SPK W EN54-24, 60x60, BLK

JBL AW566-LS-BK 15" High-Power All-Weather Speaker with EN54-24 Compliance

The AW566-LS-BK is a robust outdoor loudspeaker engineered for mission-critical applications where reliability and consistent coverage cannot fail. Its all-fiberglass, weather-resistant construction and integrated 400W transformer make it equally at home on stadium grounds, outdoor venues, or safety-critical installations requiring life-safety certification.

Audio Performance & Coverage

A dual voice-coil 2265H 380mm (15-inch) woofer paired with a 2432H compression driver delivers high-output sound across 60° × 60° coverage via Progressive Transition wave-guide technology, ensuring even directivity and minimal off-axis coloration. The integrated 400W transformer supports both 70/100V distributed systems and direct 8-ohm connections, providing deployment flexibility across different installation topologies.

Design & Durability

All-fiberglass enclosure construction and 14-gauge stainless steel grille with open-cell foam and stainless steel mesh backing withstand outdoor elements and UV exposure. The included corrosion-resistant, extra-thick zinc-plated polyester powder-coated U-type mounting bracket features dual M10 suspension points, M6 aiming stabilization, and rear M10 safety attachment for secure installation.

Key Features

• 2265H 380mm (15-inch) low-frequency driver with dual voice coil and dual magnetic gap
• 2432H high-frequency compression driver with 38mm (1.5-inch) exit and 75mm (3-inch) voice coil
• 60° × 60° coverage pattern via large-format Progressive Transition wave-guide
• Vertical or horizontal orientation capability
• All-fiberglass weather-resistant enclosure
• 14-gauge stainless steel grille with open-cell foam and stainless steel mesh backing
• Integrated 400W transformer supporting 70/100V and 8-ohm direct connections
• EN 54-24 compliant for life-safety applications
• Corrosion-resistant extra-thick zinc-plated polyester powder-coated U-type mounting bracket included
• Dual M10 suspension attachments, M6 aiming stabilization, M10 rear safety attachment
• Black finish

The AW566-LS-BK combines professional-grade audio performance with engineered durability, making it the standard choice for outdoor and life-safety sound reinforcement.
