JBL AW266-BK 12" HI-PWR ALL-WEATHER LOUDSPEAKER, 60x60, BLK
- Brand new in original box
- Full JBL manufacturer's warranty
- Free shipping in the continental US
In stock
- SKU
- AW266-BK
Description
JBL AW266-BK 12" High-Power All-Weather Loudspeaker, 60×60°, Black
The AW266-BK is a robust, weather-sealed loudspeaker engineered for demanding outdoor and covered-venue installations where reliability and output cannot be compromised. Its compact profile and flexible mounting allow rapid deployment in fixed or portable setups, while the all-weather construction ensures performance across seasons and climates.
Recording & Reinforcement Coverage
This system delivers 126 dB SPL maximum output (132 dB peak) with 98 dB sensitivity, making it capable of covering large outdoor areas with clear, intelligible sound. The 60° × 60° coverage pattern with 12 dB directivity index maintains consistent acoustic output across the coverage zone while minimizing spillover, ideal for capturing or reinforcing sound in stadiums, theme parks, and wide-format installations without acoustic bleed into unwanted zones.
Build Quality & Environmental Durability
A multilayer glass composite enclosure with heavy internal bracing resists UV damage, temperature extremes, and physical impact. The 14-gauge stainless steel grille backed with open-cell foam and stainless steel mesh provides both protection and weather resistance while maintaining acoustic transparency.
Key Features
- JBL Differential Drive dual voice coil and dual magnetic gap 300 mm (12 in) low-frequency driver
- 2432H high-frequency compression driver with 38 mm (1.5 in) exit and 75 mm (3 in) voice coil
- Frequency range (-10 dB): 40 Hz – 20 kHz
- Frequency response (±3 dB): 51 Hz – 18 kHz
- System sensitivity: 98 dB (1W @ 1m)
- Maximum SPL: 126 dB (132 dB peak)
- Long-term power rating: 500 W (2000 W peak) with 400 W 70/100V transformer
- 70V/100V transformer taps: 70V at 400 W, 200 W, 100 W; 100V at 400 W, 200 W
- Directivity index: 12 dB
- 60° × 60° coverage pattern
- Multilayer glass composite enclosure with heavy internal bracing
- Heavy-duty weather-treated U-type mounting bracket included; vertical or horizontal orientation
The AW266-BK combines high-output capability, weather-sealed construction, and precise directional control—a dependable tool for professional outdoor recording and live sound work.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The AW266-BK is a permanent-installation or broadcast-quality outdoor PA speaker engineered for fixed-venue sound reinforcement rather than studio recording. Its weather-sealed construction, high directivity index, and 70/100V transformer network make it suited to stadium, theme-park, or outdoor event workflows—not mixing or tracking. Studio owners and producers won't find recording applications for this speaker; it's purpose-built for live reinforcement and venue deployment.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Stadium/Large Venue Sound Reinforcement
- ✓ Theme Park Audio
- ✓ Outdoor Events
- ✓ Permanent Installation
Not the best pick for
- – Home Recording
- – Studio Sessions
- – Practice
Skill level: Professional
Frequently Asked Questions
What does the 60°×60° coverage pattern mean, and how does it help?
The speaker focuses sound in a 60-degree horizontal and vertical cone, maintaining consistent output across that zone while minimizing spillover beyond the intended coverage area. This directional control is essential in large venues where you need to avoid feeding back into open areas or wasting energy on regions you're not trying to reach.
Can I use this speaker outdoors year-round?
Yes. The multilayer glass composite enclosure, stainless steel grille and mesh, and weather-treated mounting bracket are all engineered to resist UV damage, temperature extremes, and moisture. It's rated for permanent outdoor installation across varying climates.
What are the 70V and 100V transformer options, and which should I choose?
The built-in transformer lets you configure the speaker for either 70V or 100V line-level systems with switchable power taps (400 W, 200 W, or 100 W). Use 70V for smaller to medium installations; use 100V for longer cable runs or larger multi-speaker arrays where voltage drop becomes a concern.
What is the frequency response, and will it handle speech and music clearly?
The speaker covers 51 Hz to 18 kHz (±3 dB), with a 12-inch woofer and compression driver handling both low-end punch and high-frequency clarity. This range supports intelligible speech, announcements, and full-spectrum music reinforcement in outdoor and stadium settings.
How much power does it need, and what mounting options are included?
Long-term power rating is 500 W (2000 W peak); the unit arrives with a heavy-duty weather-treated U-type bracket supporting both vertical and horizontal orientation. Mounting is flexible for fixed installations, portable rigs, or temporary deployments.
