JBL AM7315/95-WH 3-Way Full-Range Loudspeaker System

The AM7315/95-WH is a three-way professional loudspeaker engineered for demanding live sound and installation applications. Its rotatable cabinet design and 90 × 50 coverage pattern deliver consistent performance whether deployed horizontally or vertically, making it adaptable to diverse venue configurations. Built from 16 mm Finnish birch plywood in a durable white finish, this system combines structural integrity with a clean, professional appearance.

Audio Performance & Coverage

The triaxial driver configuration—featuring a 380 mm low-frequency driver, 200 mm midrange compression driver, and 38 mm high-frequency compression driver—delivers extended frequency response from 38 Hz to 20 kHz (-10 dB). Peak output reaches 141 dB SPL in tri-amp configuration, with 600W power handling, providing sufficient headroom for installed systems and mobile applications. High-slope crossovers minimize band overlap for arrayable, well-controlled off-axis response that translates across the listening field.

Build & Suspension Design

Thirteen M10 threaded suspension points provide flexible rigging options for both ground-stacked and hung deployments. The DuraFlex finish in white resists moisture and UV degradation, ensuring longevity in permanent installations and outdoor environments. This construction approach prioritizes both reliability and quick setup across varying installation scenarios.

Key Features

• 380 mm (15 inch) Differential Drive low-frequency driver
• 200 mm (8 inch) CMCD Cone Midrange Compression Driver
• 38 mm exit / 75 mm voice-coil HF compression driver
• 90 × 50 coverage pattern, rotatable for horizontal or vertical cabinet orientation
• Frequency response: 38 Hz to 20 kHz (-10 dB)
• Maximum SPL: 141 dB (tri-amp)
• 600W power handling
• 16 mm (5/8 inch) exterior-grade 11-ply Finnish birch plywood construction
• Bi-Amp/Tri-Amp switchable configuration
• High-slope crossovers with minimized band overlap
• 13 M10 threaded suspension points
• White DuraFlex finish

The AM7315/95-WH serves as a versatile full-range system for live sound professionals and venue operators requiring proven directivity control, extended frequency response, and reliable capture of program material across diverse acoustic environments.
