JBL AM7215/95-WH Two-way full range loudspeaker (white)

JBL AM7215/95-WH Two-way Full Range Loudspeaker

The AM7215/95-WH is a professional-grade two-way system engineered for consistent, controlled coverage in installed sound applications. Its compact footprint and rotatable waveguide make it equally at home mounted horizontally or vertically, while the DuraFlex finish white enclosure resists wear in demanding environments. Built on JBL's proven compression driver topology, this speaker delivers articulate midrange clarity paired with authoritative low-frequency extension.

Design & Build Quality

The enclosure is constructed from heavily braced multi-ply birch finished in JBL's durable DuraFlex coating, with a 14-gauge steel grille internally lined with acoustically transparent foam for protection without sonic compromise. Fifteen M10 threaded suspension points provide secure rigging options, and the rotatable waveguide allows quick field adaptation between portrait and landscape mounting orientations.

Acoustic Performance & Power Handling

This system produces a 96 dB SPL @ 1W/1m sensitivity rating, enabling efficient operation with modest amplifier power while maintaining clean headroom. The 1.2 kHz crossover seamlessly integrates a dual voice coil, dual magnetic gap 15-inch woofer with a 1.5-inch compression driver, delivering 40 Hz–20 kHz (±3 dB) response and 128 dB continuous SPL (134 dB peak) in bi-amplified mode, or 124 dB continuous SPL (130 dB peak) in passive mode.

Key Features

• 15-inch low-frequency driver with dual voice coil and dual magnetic gap design
• 1.5-inch compression driver with 3-inch voice coil
• Frequency response: 40 Hz – 20 kHz (±3 dB)
• Frequency range: 34 Hz – 20 kHz (-10 dB)
• System sensitivity: 96 dB SPL @ 1 watt/1 meter (passive mode)
• Crossover frequency: 1.2 kHz
• 90 × 50° coverage pattern
• 8 Ohm nominal impedance
• Long-term power rating: 600W passive (2400W peak, 100 hrs)
• Maximum SPL: 128 dB continuous (134 dB peak) bi-amp; 124 dB continuous (130 dB peak) passive
• Rotatable waveguide for vertical or horizontal orientation
• Bi-amplified capable with separate amplification for high and low frequency drivers

The AM7215/95-WH combines rugged construction, efficient amplification, and predictable directional control—making it a dependable choice for installed venues, houses of worship, and live sound applications where reliability and speech intelligibility matter.
