JBL AM7215/66-WH Two-way full range loudspeaker (white)
Description
JBL AM7215/66-WH Two-way Full Range Loudspeaker (White)
The AM7215/66-WH is a professional-grade two-way loudspeaker engineered to deliver controlled, articulate sound across studio monitoring applications and live tracking environments. Its trapezoid cabinet design and rotatable waveguide accommodate both vertical and horizontal placement, allowing flexible positioning in control rooms and tracking spaces without acoustic compromise. Built on JBL's proven Differential Drive architecture, this speaker captures authoritative low-end extension paired with articulate high-frequency detail—essential for accurate mix translation and source monitoring during recording sessions.
Acoustic Performance & Coverage
The 2265H dual voice coil driver (380 mm / 15 in) handles low frequencies with 98 dB SPL sensitivity at 1W, while the 2432H compression driver (38 mm exit, 75 mm voice coil) provides 114 dB SPL in the high frequencies. The 60 × 60° Progressive Transition waveguide ensures uniform directivity across the midrange and treble, maintaining consistent coverage patterns from listening positions in the control room or around the tracking space. Frequency response holds ±3 dB from 40 Hz to 18 kHz, with full-spectrum extension down to 34 Hz at −10 dB—delivering the low-frequency clarity and high-end definition needed for precise monitoring and mix decisions.
Construction & Connectivity
The cabinet is fabricated from multi-ply birch with DuraFlex finish and internal bracing for rigidity and durability in professional studio environments. Fifteen M10 threaded attachment points enable secure wall or console mounting, while the acoustically transparent foam-lined 14-gauge steel grille protects drivers without sonic coloration. Dual input options—NL4 Neutrik Speakon and CE-compliant barrier strip terminals—support both bi-amped operation via external processors and passive configuration, adapting to your mixing console's output topology and signal chain requirements.
Key Features
- 2265H 380 mm (15 in) dual voice coil, dual magnetic gap Differential Drive LF driver
- 2432H compression driver with 38 mm exit and 75 mm voice coil
- LF sensitivity 98 dB SPL (1W @ 1m); HF sensitivity 114 dB SPL (1W @ 1m)
- Frequency response ±3 dB from 40 Hz to 18 kHz; 34 Hz to 20 kHz at −10 dB
- 60 × 60° coverage pattern via Progressive Transition waveguide
- 8 ohm nominal impedance; bi-amped or passive switchable configuration
- 1000 W continuous (4000 W peak, 2 hrs) LF; 100 W continuous (400 W peak) HF capacity
- Multi-ply birch with DuraFlex finish; heavily braced construction
- Fifteen M10 threaded attachment points for flying or fixed mounting
- NL4 Neutrik Speakon and barrier strip terminal inputs
- Rotatable waveguide for vertical or horizontal orientation
- 60 lbs (27.2 kg) weight; Mil-Std 810 environmental compliance; IP-x3 per IEC529
The AM7215/66-WH combines extended frequency response, controlled directivity, and flexible mounting in a proven professional design suited to studio monitoring, tracking environments, and precision audio work.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM7215/66-WH is a professional full-range speaker engineered for live-sound applications and fixed installations—not a studio recording tool. If your work involves mixing FOH or monitoring in live venues, touring, or running a permanent installation system, this speaker's controlled directivity and consistent frequency response serve as a reference for how your mix translates to the room. Its Differential Drive architecture and high SPL output (98 dB LF, 114 dB HF) make it valuable for validating mixes in real-world acoustic environments, but it is not designed for studio recording, tracking, or mixing at close proximity.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Fixed Installation
- ✓ Large Venue Coverage
Not the best pick for
- – Home Recording
- – Practice
Skill level: Professional
Frequently Asked Questions
What kind of venues and applications is this speaker designed for?
The AM7215/66-WH is engineered for live performance, touring, and fixed installations in venues requiring consistent sound reinforcement across medium to large spaces. Its 60×60° coverage pattern, high output (98 dB LF / 114 dB HF sensitivity), and durable construction make it suited to touring rigs, permanent installations, and challenging acoustic environments.
How does the coverage pattern work, and can I rotate it?
The 60×60° Progressive Transition waveguide delivers uniform directivity across midrange and treble, ensuring consistent coverage from different listening positions. The waveguide is rotatable, so you can orient the speaker vertically or horizontally to match your venue layout without compromising acoustic performance.
What inputs and amplifier configurations does it support?
The AM7215/66-WH has dual input options: NL4 Neutrik Speakon connectors (touring standard) and CE-compliant barrier strip terminals (permanent installations). It can operate in bi-amped mode (separate amplifier channels for LF and HF) or passive mode, giving you flexibility across different system architectures.
What is the frequency response and how much power can it handle?
Frequency response is ±3 dB from 40 Hz to 18 kHz, with extension to 34 Hz at −10 dB. The LF driver handles 1000 W continuous (4000 W peak, 2 hours), and the HF driver handles 100 W continuous (400 W peak), making it suitable for high-output installations and touring applications.
Is this speaker rugged enough for touring and outdoor use?
Yes. The cabinet is multi-ply birch with DuraFlex finish and internal bracing for durability in demanding environments. It is Mil-Std 810 compliant and IP-x3 rated per IEC529, with 15 M10 threaded attachment points for secure flying or fixed mounting on any tour or installation.
