JBL AM7215/64-WH Two-way full range loudspeaker (white)

JBL AM7215/64-WH Two-Way Full Range Loudspeaker

The AM7215/64-WH is a mid-to-large format two-way system engineered for consistent, articulate output in studio monitor applications and live recording sessions. Its trapezoidal birch enclosure delivers solid thermal mass and rigidity, while the rotatable waveguide accommodates both vertical and horizontal mounting orientations without repositioning the entire cabinet. This is a dependable design built to maintain coherent coverage and SPL output across extended tracking and monitoring sessions.

Acoustic Design & Coverage

The pairing of a 2265H 15-inch low-frequency driver with dual voice coil and dual magnetic gap to a 2432H compression driver produces a 60 x 40 degree coverage pattern with a 1.8 kHz passive crossover frequency. This architecture ensures smooth integration across the frequency spectrum and maintains even tonal balance throughout the control room or studio space, making the system ideal for critical monitoring during recording, mixing, and mastering work.

Power Handling & Output Capability

The AM7215/64-WH delivers 123 dB continuous SPL (129 dB peak) in passive mode, with significantly higher output available in bi-amp configuration: 128 dB continuous for the LF driver and 135 dB continuous for the HF driver. Its 600W power rating and switchable bi-amp/passive operation provide flexibility in system integration while maintaining clean headroom for detailed mix assessment and real-time session monitoring.

Key Features

• 2265H 380 mm (15 in) low-frequency driver with dual voice coil and dual magnetic gap
• 2432H high-frequency compression driver with 38 mm (1.5 in) exit and 75 mm (3 in) voice coil
• 60 x 40 degree coverage pattern
• 1.8 kHz passive crossover frequency
• 123 dB continuous (129 dB peak) SPL in passive mode; 128 dB continuous (134 dB peak) LF and 135 dB continuous (141 dB peak) HF in bi-amp mode
• 600W power rating
• Multi-ply birch wood enclosure with JBL DuraFlex finish and trapezoidal shape
• 14-gauge steel grille internally lined with acoustically transparent foam
• NL4 Neutrik Speakon and barrier strip terminals accepting up to 5.2 sq mm (10 AWG) wire or 9 mm spade lugs
• 15 M10 threaded suspension points
• Rotatable waveguide for vertical or horizontal orientation
• Bi-amp/passive switchable operation with IP-x3 rating and Mil-Std 810 environmental compliance

The AM7215/64-WH combines proven driver technology, solid construction, and operational flexibility to serve as a reliable monitoring solution in studio and production environments requiring sustained output and consistent coverage for accurate mix translation.
