JBL AM7212/64-WH Two-way full range loudspeaker (white)
Description
JBL AM7212/64-WH Two-Way Full Range Loudspeaker
The AM7212/64-WH is a professional-grade two-way system engineered for consistent, high-output performance in midsize venues, installed sound applications, and touring rigs. Its trapezoidal cabinet design and rotatable waveguide provide flexible deployment options, while the white finish integrates seamlessly into corporate, educational, and performance environments. This is a workhorse speaker built to deliver reliable output session after session, night after night, without compromise.
Audio Performance & Coverage
The system combines a 2262H 12-inch LF driver with dual voice coil and dual magnetic gap construction alongside a 2432H compression driver (1.5-inch exit, 3-inch voice coil) for articulate high-frequency reproduction. With a 1.8 kHz crossover point and 60 × 40° coverage pattern, the AM7212/64-WH maintains consistent sound across medium-throw applications, while its 36 Hz to 20 kHz frequency range captures full-spectrum audio from deep bass through crisp treble, ensuring every element sits properly in the mix.
Build & Power Handling
The cabinet is constructed from 16 mm (5/8-inch) exterior-grade 11-ply Finnish birch plywood with a durable JBL DuraFlex finish, designed to withstand the demands of touring and permanent installation. Power handling reaches 1000 W continuous for the LF section (4000 W peak, 2-hour rating) and 100 W for the HF section, with 8-ohm nominal impedance and 96 dB SPL sensitivity (LF) / 115 dB SPL sensitivity (HF), enabling high-output operation in larger spaces without introducing unwanted distortion or fatigue.
Key Features
- 2-way, full-range bi-amped or passive-switchable system
- 2262H 300 mm (12 in) low-frequency driver with dual voice coil and dual magnetic gap
- 2432H high-frequency 38 mm (1.5 in) exit, 75 mm (3 in) voice-coil compression driver
- Large format Progressive Transition waveguide, rotatable for vertical or horizontal orientation
- Nominal impedance 8 ohms with 96 dB SPL (LF) and 115 dB SPL (HF) sensitivity
- Frequency range 36 Hz to 20 kHz (−10 dB)
- Coverage pattern 60 × 40°; crossover at 1.8 kHz (passive)
- LF power handling 1000 W continuous (4000 W peak, 2 hrs); HF 100 W (400 W peak)
- 16 mm (5/8 in) exterior-grade 11-ply Finnish birch plywood with JBL DuraFlex finish
- 15 M10 threaded suspension points for secure rigging and installation
- 14-gauge steel grille with acoustically transparent foam protection
- White finish (−WH designation)
The AM7212/64-WH delivers the combination of rugged construction, high output capability, and consistent coverage required for professional sound reinforcement in installed and touring applications.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM7212/64-WH is a full-range two-way system built for recording studios and project spaces that require professional monitoring or sound reinforcement in larger rooms, delivering flat, articulate response from 36 Hz to 20 kHz with minimal coloration. Its bi-amplified or passive-switchable design and rotatable waveguide allow flexible placement and orientation to suit studio layouts, while 96 dB LF and 115 dB HF sensitivity ensure dynamic headroom for mixing and mastering without distortion. Though primarily engineered for live and installed sound, its transparent frequency response and robust construction make it a capable reference monitor for producers working in larger control rooms or tracking spaces.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Installed Sound
- ✓ Corporate Events
Not the best pick for
- – Home Recording
- – Small Venue Intimacy
Skill level: Professional
Frequently Asked Questions
What is the frequency range and sensitivity of this speaker?
The AM7212/64-WH covers 36 Hz to 20 kHz (−10 dB) with 96 dB SPL sensitivity in the low-frequency section and 115 dB SPL sensitivity in the high-frequency section, enabling full-spectrum response and high output capability in medium to large venues.
Can this speaker be used in both touring and installed applications?
Yes. The cabinet is built from 16 mm exterior-grade 11-ply Finnish birch plywood with a durable JBL DuraFlex finish, designed to withstand repeated touring use, and includes 15 M10 threaded suspension points for secure rigging and permanent installation.
What is the power handling specification?
The low-frequency section handles 1000 W continuous (4000 W peak, 2-hour rating), while the high-frequency section handles 100 W continuous (400 W peak). The speaker operates at 8-ohm nominal impedance and is switchable for bi-amplified or passive operation.
What coverage pattern does this speaker provide?
The AM7212/64-WH features a 60 × 40° coverage pattern with a rotatable Progressive Transition waveguide, allowing vertical or horizontal orientation to suit medium-throw venues and installed sound applications with consistent, predictable audience coverage.
What drivers are inside this speaker?
The system combines a 2262H 12-inch low-frequency driver with dual voice coil and dual magnetic gap construction and a 2432H compression driver with a 1.5-inch exit and 3-inch voice coil, crossed over at 1.8 kHz for articulate high-frequency reproduction.
