JBL AM7212/26-WH Two-way full range loudspeaker (white)

JBL AM7212/26-WH Two-Way Full Range Loudspeaker

The AM7212/26-WH is a professional-grade two-way loudspeaker engineered for studio monitoring applications, small-to-medium venue reinforcement, and mobile recording setups. Its rotatable waveguide and multi-ply birch construction deliver consistent, phase-coherent coverage ideal for tracking and mixing environments, while the compact footprint and 51 lb weight make it practical to position and integrate into various studio configurations and mobile rigs.

Driver Configuration & Coverage

This system pairs a 2262H 12-inch low frequency driver with dual voice coil and dual magnetic gap architecture against a 2432H high frequency compression driver featuring a 1.5-inch exit and 3-inch voice coil. The large-format Progressive Transition waveguide delivers 120 × 60° coverage, ensuring smooth directional control and consistent sound across the mix position without phase cancellation or acoustic coloration.

Construction & Flexibility

Heavy internal bracing and multi-ply birch enclosure with DuraFlex finish provide rigidity and protection in both studio and field environments. The rotatable waveguide allows both vertical and horizontal mounting orientations to optimize placement within control rooms or live tracking spaces, while fifteen M10 threaded attachment points accommodate monitor mounts, wall brackets, and stand integration; the 14-gauge steel grille with acoustically transparent foam lining protects drivers without coloration.

Key Features

• 2262H 12-inch low frequency driver with dual voice coil and dual magnetic gap
• 2432H high frequency compression driver with 1.5-inch exit and 3-inch voice coil
• Large-format Progressive Transition waveguide with 120 × 60° coverage pattern
• Rotatable waveguide for vertical or horizontal orientation
• Multi-ply birch enclosure with DuraFlex finish, heavily internally braced
• 14-gauge steel grille with acoustically transparent foam lining
• Bi-Amp/Passive switchable configuration
• High-slope passive networks minimize band overlap
• Fifteen M10 threaded attachment points for rigging and installation
• Weight: 51 lbs (23.1 kg)

The AM7212/26 combines proven driver technology with flexible mounting and proven field durability, making it suitable for both temporary and permanent installations.
