JBL AM7212/00-WH S/m, AM7212/00 Wh B-Stock
Share
In stock
Only 1 left
- SKU
- AM7212-00-WH-B
. Description
JBL AM7212/00-WH Compact Loudspeaker System
The AM7212/00-WH is a compact yet powerful full-range loudspeaker engineered for studio monitoring, portable recording rigs, and project studio installations where consistent acoustic performance matters. Its rotatable waveguide and multiple suspension points allow flexible positioning in the control room or tracking space, adapting to room geometry without sacrificing sonic integrity. The white DuraFlex finish and perforated steel grille offer clean aesthetics while maintaining rugged durability through extended studio sessions and transport.
Sonic Character & Translation
This system delivers balanced response across the full audio spectrum, with 42 Hz to 20 kHz response (±3 dB) and extended low-end reach down to 36 Hz at -10 dB, providing the foundation needed to track bass and kick with confidence. The 95 dB SPL @ 1W/1m sensitivity means efficient amplifier power conversion for clear, fatigue-free mixing at moderate levels, while the 100 × 100° coverage pattern creates a cohesive sweet spot across the mixing position, reducing room reflections and providing an honest window into your mix.
Construction & Studio Durability
The enclosure is constructed from multi-ply birch with heavy internal bracing and finished in DuraFlex coating to resist dust accumulation, temperature swings, and the wear of frequent repositioning. The 14-gauge perforated steel grille with acoustically transparent foam protects the drivers while maintaining sonic transparency, and the 15 M10 threaded suspension points support flexible mounting on stands, racks, or wall brackets for precise acoustic placement. Environmental certification to Mil-Std 810 and IP-x3 (IEC529) ensures reliable operation in varied studio environments.
Key Features
- Frequency Response: 42 Hz – 20 kHz (±3 dB); Range 36 Hz – 20 kHz (-10 dB)
- Nominal Impedance: 8 Ohms
- System Sensitivity (Passive mode): 95 dB SPL @ 1 watt/1 meter
- 2262H 300mm (12 in) low-frequency driver with Differential Drive technology
- 2432H high-frequency compression driver with 38 mm exit and 75 mm voice-coil
- Passive Crossover Frequency: 1.5 kHz
- Maximum SPL (Bi-amp mode): LF 126 dB continuous / 132 dB peak; HF 131 dB continuous / 137 dB peak
- Maximum SPL (Passive mode): 123 dB continuous / 129 dB peak
- Long-Term Power Rating (Passive): 600W AES (2400W peak, 100 hrs)
- 100 × 100° coverage area with rotatable waveguide
- Multi-ply birch enclosure with DuraFlex finish and heavy bracing
- 15 M10 threaded suspension/mounting points; Mil-Std 810 & IP-x3 rated
The AM7212/00-WH balances compact footprint with substantial output capability, making it a practical reference tool for studios where space constraints demand a well-engineered monitoring solution.
More Information
| Condition | Refurbished |
|---|
Reviews
At a Glance
The JBL AM7212/00-WH is a professional-grade full-range monitor and reinforcement speaker ideal for recording studios and live-tracking setups where accurate, wide-coverage playback matters. Its 42 Hz–20 kHz response (±3 dB), 95 dB sensitivity, and efficient power conversion make it a dependable reference tool for mix validation in mid-sized rooms without coloration or hot zones. Select it when your production space needs a single compact solution that translates mixes reliably across the frequency spectrum.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Worship
- ✓ Events
- ✓ Fixed Installation
Not the best pick for
- – Home use
- – Portable DJ setups
Skill level: Professional
Frequently Asked Questions
What does B-Stock mean?
B-Stock indicates the AM7212/00-WH is fully functional and meets all performance specifications, but may have minor cosmetic imperfections such as finish marks or grille blemishes from handling or return. All audio and structural components operate at full rating.
Can this speaker be mounted both vertically and horizontally?
Yes. The rotatable waveguide and 15 M10 threaded suspension points allow flexible rigging in either orientation without sacrificing coverage or tonal balance, adapting to room geometry and installation needs.
What is the maximum SPL output?
In passive mode, the AM7212/00-WH delivers 123 dB continuous / 129 dB peak SPL. Bi-amp mode increases this to 126 dB continuous / 132 dB peak for the low-frequency driver and 131 dB continuous / 137 dB peak for the high-frequency driver.
Is this speaker suitable for outdoor use?
Yes. The multi-ply birch enclosure is finished in DuraFlex coating and rated to IP-x3 (IEC529) for water and dust resistance, plus Mil-Std 810 environmental certification, making it suitable for outdoor and semi-covered installations.
What frequency range does it cover?
The AM7212/00-WH covers 42 Hz–20 kHz (±3 dB), with extended reach down to 36 Hz at -10 dB, ensuring full-range performance across vocals, instruments, and low-end content without gap or muddiness.
Do I pay sales tax on this order?
We collect sales tax only on orders shipped to California. Orders shipped to any other US state are charged $0 sales tax at checkout when you buy direct from our website. On this item that is roughly $212 less out the door than the same listed price at a national retailer or on a marketplace. Marketplaces such as eBay, Reverb and Amazon collect sales tax in nearly every state as marketplace facilitators no matter who the seller is, so the same item at the same price costs less bought direct. Free US shipping and 30-day returns are included. Some states ask buyers to self-report use tax on out-of-state purchases.
