JBL AM5215/95-WH Two-way full range loudspeaker (white)

JBL AM5215/95-WH Two-Way Full Range Loudspeaker (White)

The AM5215/95-WH is a professional-grade two-way loudspeaker engineered to deliver consistent, predictable coverage and reliable output across studio monitoring, live recording, and sound reinforcement applications. Its rotatable progressive transition waveguide accommodates both vertical and horizontal mounting, adapting to room acoustics and mic placement strategies in tracking and mixing environments. Built on proven JBL engineering, this speaker captures the output and frequency response needed for accurate reference monitoring, full-range source reinforcement, and detailed sound distribution in mid-to-large studio and venue spaces.

Driver Configuration & Coverage

The system pairs a 265H-1 380 mm (15 in) dual voice coil, dual magnetic gap Differential Drive low-frequency driver with a 2408H-1 compression driver featuring a 38 mm exit and 38 mm voice coil. This combination crosses over at 1.8 kHz and delivers consistent 90 x 50° coverage, ensuring even acoustic reach across the control room or tracking space without phase cancellations or proximity-induced coloration.

Output & Frequency Response

The AM5215/95-WH produces 124 dB SPL continuous average (130 dB peak) with a system sensitivity of 98 dB SPL @ 1 watt / 1 meter, providing enough headroom for dynamic tracking and real-time mix adjustments without compression or distortion. Its 41 Hz – 18 kHz frequency response (±3 dB) and extended 35 Hz – 20 kHz range (-10 dB) reveal the full harmonic complexity of instruments and vocals, while the 350W long-term power rating (1400W peak) sustains transient detail and punch across all session content.

Key Features

• 265H-1 380 mm (15 in) dual voice coil, dual magnetic gap Differential Drive low-frequency driver
• 2408H-1 38 mm exit, 38 mm voice coil compression driver
• 1.8 kHz crossover frequency
• Frequency response: 41 Hz – 18 kHz (±3 dB)
• Extended frequency range: 35 Hz – 20 kHz (-10 dB)
• System sensitivity: 98 dB SPL @ 1 watt / 1 meter (passive mode)
• Maximum SPL: 124 dB continuous average / 130 dB peak
• Long-term power rating: 350W (1400W peak), 100 hrs IEC, passive mode
• 90 x 50° coverage pattern
• Progressive transition waveguide with rotatable orientation (vertical or horizontal)
• Bi-amp/passive switchable operation
• 8 Ohm nominal impedance with NL4 speakON and barrier strip inputs

The AM5215/95-WH combines robust drivers, flexible mounting, and reference-class output to meet the demands of professional recording, live tracking, and high-resolution mixing workflows.
