JBL AM5215/64-WH Two-way full range loudspeaker (white)
Description
JBL AM5215/64-WH Two-way Full Range Loudspeaker (White)
The AM5215/64-WH is a professional full-range loudspeaker engineered for accurate sound reproduction in recording studios, broadcast facilities, and monitoring applications. Its compact yet rigid cabinet delivers articulate coverage across a wide frequency spectrum, with the flexibility to orient the horn vertically or horizontally depending on your studio setup and monitoring placement.
Audio Performance
Frequency response extends from 41 Hz to 18 kHz, providing full-spectrum coverage from deep bass through crisp highs for mixing and mastering work. The dual-component driver design pairs a 380 mm (15 in) low frequency driver with differential drive technology alongside a 38 mm (1.5 in) exit/voice-coil compression driver, achieving 98 dB SPL sensitivity (1W @ 1m) for transparent monitoring at practical working levels in both passive and bi-amped configurations.
Design & Build
The cabinet is constructed from heavily braced multi-ply birch finished in JBL's DuraFlex coating for long-term reliability in demanding studio environments. A 14-gauge steel grille with internally lined acoustically transparent foam protects the drivers while maintaining sonic transparency, secured by fifteen M10 threaded attachment points for reliable, tool-free installation and repositioning.
Key Features
- 380 mm (15 in) JBL Differential Drive low frequency driver with dual voice coil and dual magnetic gap
- 38 mm (1.5 in) exit/voice-coil compression driver (2408H-1) for precise mid and high frequency reproduction
- 60 x 40° coverage pattern for controlled directional projection
- Frequency response: 41 Hz to 18 kHz
- 98 dB SPL sensitivity (1W @ 1m) in passive mode
- Bi-amped or passive switchable operation for flexible system configuration
- NL4 Neutrik speakON connectors and CE-compliant covered barrier strip terminals
- Rotatable horn deployable in vertical or horizontal orientation
- Multi-ply birch cabinet with DuraFlex finish
- Heavily braced construction for cabinet rigidity and reduced resonance
- 14-gauge steel grille with integrated acoustically transparent foam lining
- Fifteen M10 threaded attachment points for secure mounting and stacking
The AM5215/64-WH combines JBL's professional driver technology with field-proven construction to deliver reliable, articulate monitoring across mixing, mastering, and tracking sessions.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM5215/64-WH is a professional full-range reference monitor and studio reinforcement speaker that captures a clean, articulate frequency response from 41 Hz to 18 kHz with 98 dB sensitivity, making it ideal for tracking, mixing, and mastering in acoustically treated rooms. Its dual-component driver design—15-inch differential-drive woofer plus compression driver—delivers precise mid and high-end detail while the rotatable horn lets you tune coverage to your room layout. Built on JBL's field-proven platform and designed for bi-amped or passive operation, it brings live-venue reliability and consistent sound to professional recording and mixing environments.
Who This Is For
Great for
- ✓ Live Performance
- ✓ House of Worship
- ✓ Installed Sound
- ✓ Studio Monitoring
Not the best pick for
- – Home Practice
- – Bedroom Recording
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What's the frequency response and sensitivity?
The AM5215/64-WH covers 41 Hz to 18 kHz and delivers 98 dB SPL at 1 watt at 1 meter, making it efficient enough to run passively or bi-amped depending on your system design.
Can I mount this in different orientations?
Yes—the 60×40° horn rotates between vertical and horizontal mounting, and the cabinet features fifteen M10 threaded attachment points for flexible installation and secure stacking.
What's included for connectivity?
The speaker comes with NL4 Neutrik speakON connectors and CE-compliant covered barrier strip terminals, allowing both professional audio XLR-style connections and traditional barrier-strip wiring.
Is this speaker suitable for studio monitoring or mainly live sound?
While it's designed primarily for live venues, houses of worship, and installed sound, its articulate full-spectrum response and controlled directivity make it suitable for studio reinforcement and reference monitoring in treated acoustic spaces.
What's the cabinet construction like?
The AM5215/64-WH uses heavily braced multi-ply birch with JBL's DuraFlex finish and a 14-gauge steel grille with acoustically transparent foam lining, delivering durability and rigidity for demanding touring and installation environments.
