JBL AM5212/66 Two-way full range loudspeaker
Share
- Brand new in original box
- Full JBL manufacturer's warranty
- Free shipping in the continental US
Out of stock
- SKU
- AM5212-66
. Description
JBL AM5212/66 Two-way Full Range Loudspeaker
The AM5212/66 is a compact yet powerful full-range loudspeaker engineered for professional recording and monitoring applications. Its rotatable waveguide design and balanced construction deliver consistent imaging whether positioned vertically or horizontally in control rooms, live tracking spaces, and hybrid studio setups. Built on JBL's proven platform, this cabinet captures articulate midrange and extended low-end response ideal for tracking sessions, mixing references, and portable recording rigs that demand transparent, reliable sound reproduction.
Acoustic Performance & Coverage
The dual-component design pairs a 262H-1 300 mm (12 in) low frequency driver with dual voice coil and dual magnetic gap with a 2408H-1 compression driver featuring a 38 mm (1.5 in) exit and voice-coil, producing 1600W peak / 300W RMS output at 8 Ohms nominal impedance. The 60° x 60° coverage pattern ensures even frequency response and consistent staging across typical control room and tracking space dimensions, minimizing acoustic dead zones and room interaction artifacts.
Build Quality & Studio Durability
The cabinet employs a multiply birch enclosure with JBL's rugged DuraFlex™ finish for sustained performance in active studio environments, while the 14-gauge steel grille internally lined with acoustically transparent foam protects drivers without veiling high-end clarity or coloring the mix. Environmental rating to Mil-Std 810 and IP-x3 per IEC529 confirms this speaker's resilience against temperature fluctuation, vibration, and humidity typical of working studios and field recording applications.
Key Features
- 262H-1 300 mm (12 in) low frequency driver with dual voice coil and dual magnetic gap
- 2408H-1 compression driver with 38 mm (1.5 in) exit and voice-coil
- 1600W Peak / 300W RMS power handling
- 8 Ohms nominal impedance
- 60° x 60° rotatable waveguide coverage
- Multiply birch enclosure with DuraFlex™ finish
- 14-gauge steel grille with internally lined acoustically transparent foam
- Dimensions: 28.06" H x 14.6" W x 18.1" D (713 x 371 x 458 mm)
- Net Weight: 45 lbs (20.2 kg)
- NL4 Neutrik speakON® and barrier strip terminals
- Bi-amped or passive operation modes
- Environmental rating: Mil-Std 810; IP-x3 per IEC529
The AM5212/66 combines proven JBL component quality, flexible mounting versatility, and transparent acoustic character into a mid-sized enclosure that integrates efficiently across multiformat recording and mixing workflows.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The AM5212/66 is a versatile full-range installed or portable speaker that pairs a 300mm woofer with a compression driver to capture articulate mids and extended low-end—useful for recording live sound reinforcement, capturing band rehearsals, or monitoring in project studios that need professional reference-grade SPL. Its balanced two-way design and flexible mounting orientation make it adaptable to unconventional room layouts, while the 60° × 60° coverage ensures even sound distribution across tracking or mixing spaces. Choose it for durability, transparent driver protection, and the ability to monitor and capture full-frequency content without coloration.
Who This Is For
Great for
- ✓ houses of worship
- ✓ corporate installations
- ✓ live performance
- ✓ touring
- ✓ small venues
Not the best pick for
- – home listening
- – bedroom practice
Skill level: Intermediate · Advanced · Professional
Frequently Asked Questions
What are the main speaker components and power handling?
The AM5212/66 pairs a 262H-1 300mm (12-inch) low-frequency driver with dual voice coil and dual magnetic gap with a 2408H-1 compression driver featuring a 38mm (1.5-inch) exit and voice coil, producing 1600W peak and 300W RMS output at 8 Ohms nominal impedance.
Can the speaker be mounted in different orientations?
Yes, the rotatable waveguide design allows vertical or horizontal mounting to adapt to venue constraints without sacrificing coverage or clarity, and the consistent 60° × 60° coverage pattern ensures even distribution across typical spaces.
Is this speaker suitable for touring and outdoor use?
Yes, the multiply birch enclosure with DuraFlex finish, 14-gauge steel grille with acoustically transparent foam lining, and environmental rating to Mil-Std 810 and IP-x3 per IEC529 confirm durability in temperature swings, vibration, and moisture typical of touring and permanent installations.
What are the dimensions and weight?
The cabinet measures 28.06 inches H × 14.6 inches W × 18.1 inches D (713 × 371 × 458 mm) and weighs 45 lbs (20.2 kg), making it portable yet substantial enough for professional installed sound.
What connection options and operating modes are available?
The AM5212/66 features NL4 Neutrik speakON and barrier strip terminals, and supports both bi-amped and passive operation modes for flexible system integration.
