JBL AM5212/26 Two-Way Full Range Loudspeaker

The AM5212/26 is a versatile studio and project-room monitor capable of delivering articulate, full-spectrum sound for mixing, mastering, and tracking applications. This two-way system combines a robust 12-inch woofer with a high-frequency compression driver in a heavily braced birch enclosure, offering genuine flexibility through both passive and bi-amped operation modes. Built to perform consistently across different room acoustics and session demands, it integrates seamlessly into home studios, project studios, and tracking rooms.

Acoustic Performance & Monitoring Characteristics

The Progressive Transition waveguide provides controlled 120° × 60° coverage with rotatable orientation to adapt to control-room geometry and listening position, while the 43 Hz – 18 kHz (±3 dB) frequency response ensures transparent reproduction from sub-bass fundamentals through vocal and cymbal detail. System sensitivity of 96 dB-SPL @ 1 watt, 1 meter combined with peak SPL ratings reaching 135 dB in bi-amp mode delivers sufficient headroom for critical listening at multiple working levels without compression or coloration.

Construction & Operational Flexibility

The multiply birch enclosure finished in JBL DuraFlex™ and extensively braced provides rigid acoustic behavior and reliable performance through extended tracking and mixing sessions. Configurable as either a passive cabinet or bi-amped system with high-slope passive networks that minimize band overlap, this speaker adapts to existing mixing console architecture and amp configuration without compromise, supporting workflow choices from powered interfaces to separate amplification.

Key Features

• Low-frequency driver: JBL Differential Drive 262H-1, 300 mm (12 in) with dual voice coil and dual magnetic gap
• High-frequency compression driver: 2408H-1, 38 mm (1.5 in) exit and voice-coil
• Progressive Transition waveguide with 120° × 60° coverage, rotatable for vertical or horizontal orientation
• Frequency Response: 43 Hz – 18 kHz (±3 dB); Frequency Range: 37 Hz – 20 kHz (-10 dB)
• Crossover Frequency: 1.5 kHz
• Nominal Impedance: 8 Ohms
• System Sensitivity: 96 dB-SPL @ 1 watt, 1 meter (passive mode)
• Maximum SPL — Bi-amp mode: LF 122 dB continuous (128 dB peak), HF 129 dB continuous (135 dB peak); Passive mode: 121 dB continuous (127 dB peak)
• Long-Term Power Rating (IEC) Passive mode: 300 W (1200 W peak, 100 hrs)
• Transducer Power Rating (AES) — LF: 400 W (1600 W peak, 2 hrs), 300 W (1200 W peak, 100 hrs); HF: 40 W (160 W peak, 2 hrs)
• Enclosure: Multiply birch with JBL DuraFlex™ finish, heavily braced
• Operates as bi-amped or passive cabinet with high-slope passive networks

The AM5212/26 stands as a dependable monitoring solution capable of capturing and mixing professional recordings whether driven passively from a mixing console or integrated into a bi-amped studio setup.
