JBL AM5212/00-WH Two-way full range loudspeaker (white)
Description
JBL AM5212/00-WH Two-Way Full Range Loudspeaker (White)
The AM5212/00-WH is a professional-grade monitor and main loudspeaker engineered to deliver consistent, controlled coverage in mid-sized studios, live tracking rooms, and mixing environments. Its trapezoid enclosure and rotatable waveguide offer flexible placement options, while the combination of a 12-inch woofer and compression driver produces balanced output across the full frequency spectrum with minimal coloration—critical for accurate mix translation and monitoring.
Recording & Monitoring Performance
This speaker reproduces audio from 43 Hz to 20 kHz, capturing the complete range of instrumental and vocal content with clarity and extended low-end reach. The PT Progressive Transition waveguide maintains tight 100° × 100° coverage throughout the frequency range, ensuring even sound distribution across the control room without phase anomalies or hot spots that compromise critical listening decisions.
Durability & Studio Integration
Built from multiply birch with DuraFlex finish, the enclosure resists warping and environmental stress while maintaining a professional appearance in the studio environment. The rotatable waveguide allows deployment in either vertical or horizontal orientation to optimize room acoustics and operator positioning, and M10 threaded attachment points accommodate flush mounting or suspension rigging. A 14-gauge steel grille protects the drivers while remaining acoustically transparent for uncolored monitoring.
Key Features
- 262H-1 Differential Drive low-frequency driver (300 mm / 12 inch)
- 2408H-1 high-frequency compression driver (38 mm / 1.5 inch exit and voice-coil)
- Frequency response: 43 Hz–20 kHz
- 100° × 100° coverage via PT Progressive Transition waveguide
- Rotatable waveguide for vertical or horizontal orientation
- Multiply birch enclosure with DuraFlex finish
- Trapezoid design with M10 threaded attachment points
- NL4 Neutrik Speakon and covered barrier strip terminals
- Switchable bi-amp and passive operation modes
- Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or 9 mm spade lugs
- Mil-Std 810 environmental specifications
- IP-x3 rated per IEC529
The AM5212/00-WH combines durable construction with professional-level acoustic performance, making it an ideal choice for permanent studio installations, mixing suites, and live tracking environments requiring predictable coverage and accurate frequency response for mix decisions.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The JBL AM5212/00-WH is a professional full-range monitor and main-speaker option for studio sessions, live recording, and worship recordings where neutral, uncolored sound reproduction is essential. Its extended frequency response (43 Hz–20 kHz), balanced driver complement, and switchable bi-amp/passive operation make it versatile for tracking, mixing reference, and session playback in acoustically demanding spaces. Choose this speaker when you need a studio-grade tool that translates mixes accurately and works equally well as a main or monitor reference in professional recording environments.
Who This Is For
Great for
- ✓ Live Performance
- ✓ Touring
- ✓ Studio Sessions
- ✓ Worship
Not the best pick for
- – Home Recording
- – Practice
Skill level: Professional
Frequently Asked Questions
What size venues and rooms is this speaker designed for?
The AM5212/00-WH is engineered for mid-sized venues and installations. Its 100° × 100° coverage from the PT Progressive Transition waveguide ensures even sound distribution without dead zones, making it ideal for touring rigs, clubs, theaters, and permanent installations where predictable coverage across a defined area is required.
Can I mount this speaker in different orientations?
Yes. The rotatable waveguide allows deployment in either vertical or horizontal orientation, and M10 threaded attachment points accommodate permanent rigging, semi-permanent stands, or floor placement depending on your venue or installation layout.
What kind of amplification and wiring does it require?
The AM5212/00-WH supports both passive and bi-amp operation modes, so you can run it from a single powered channel or split the low and high frequencies to separate amps for more control. Barrier terminals accept up to 10 AWG wire or 9 mm spade lugs, and an NL4 Neutrik Speakon connector is also provided.
How durable is this speaker for touring and outdoor use?
The enclosure is built from multiply birch with DuraFlex finish to resist warping and environmental stress. The speaker meets Mil-Std 810 environmental specifications and is IP-x3 rated per IEC 529, making it reliable for touring, semi-permanent venues, and installations exposed to variable conditions.
What drivers does this speaker use?
The AM5212/00-WH combines a 262H-1 Differential Drive 12-inch woofer (300 mm) and a 2408H-1 high-frequency compression driver (38 mm exit and voice-coil). A 14-gauge steel grille protects both drivers while remaining acoustically transparent.
