JBL AC16 Ultra Compact 2-Way Loudspeaker with 1 x 6.5 LF White
In stock
- SKU
- AC16-WH
Description
JBL AC16 Ultra Compact 2-Way Loudspeaker with 1 x 6.5" LF (White)
The JBL AC16 delivers professional-grade monitoring and reference capability in a genuinely compact footprint, making it an efficient choice for home studios, project rooms, and recording spaces where real estate is limited. This unit pairs a 6.5-inch woofer with a 1-inch compression driver tweeter, producing articulate highs and controlled lows that translate reliably to mixing decisions and playback evaluation. In honest condition with typical signs of use, this speaker retains all the sonic performance and build quality expected from JBL while offering exceptional value for tracking and mixing applications.
Monitoring Performance & Acoustic Coverage
The AC16 operates across a 55 Hz to 20 kHz frequency range (–10 dB), with a tighter ±3 dB response from 65 Hz to 18 kHz for neutral, predictable output that sits well in a mix. Its 90 x 90 coverage pattern and PT Waveguide design maintain consistent frequency response across the listening area, while the 16-ohm impedance and 160 W continuous / 320 W program / 640 W peak power handling accommodate both passive amplification and powered monitoring chains.
Build, Portability & Integration
Weighing just 7.2 kg (15.8 lb) with dimensions of 381 x 199.4 x 226.1 mm, the AC16 moves easily between rooms or repositions within a control room without compromising structural rigidity or acoustic integrity. Dual Neutrik NL4 connectors plus screw terminals provide flexible studio wiring options, and its IPx3 environmental rating per IEC529 offers protection against typical studio moisture and dust exposure.
Key Features
- 1-inch exit compression driver
- 165 mm (6.5 inch) LF transducer
- Frequency range: 55 Hz – 20 kHz (–10 dB)
- Frequency response: 65 Hz – 18 kHz (±3 dB)
- 160 W continuous / 320 W program / 640 W peak power handling
- 16-ohm impedance
- 90 x 90 coverage pattern with PT Waveguide
- Dual Neutrik NL4 connectors plus screw terminals
- Dimensions: 381.0 x 199.4 x 226.1 mm (15.0 x 7.8 x 8.9 in)
- Weight: 7.2 kg (15.8 lb)
- IPx3 environmental rating per IEC529
A proven performer ideal for nearfield monitoring, drum isolation boxes, headphone mix augmentation, or compact PA duties—this practical choice combines professional engineering with real-world studio portability and acoustic consistency.
More Information
| Condition | New |
|---|---|
| Country of Manufacture | Mexico |
Reviews
At a Glance
The JBL AC16 serves as a nearfield studio monitor or compact reference speaker, offering a tight ±3 dB response from 65 Hz to 18 kHz and clear high-end detail via its 1-inch compression driver. Its small footprint fits tight studio spaces while maintaining the balanced low-end punch needed for mixing decisions. Pick this speaker for accurate session playback and mixing in rooms where full-size monitors aren't practical.
Frequently Asked Questions
What's the frequency response and coverage pattern?
The AC16 operates from 55 Hz to 20 kHz (–10 dB), with a controlled ±3 dB response between 65 Hz and 18 kHz. Its 90×90 coverage pattern and PT Waveguide design deliver even sound distribution across mid-sized rooms and venue spaces.
Can I use this speaker in both passive and powered setups?
Yes. The AC16 handles 160 W continuous, 320 W program, and 640 W peak power at 16-ohm impedance, and includes dual Neutrik NL4 connectors plus screw terminals for flexible wiring in either configuration.
How portable is it, and does it handle outdoor or damp environments?
At 7.2 kg (15.8 lb) and compact dimensions of 381×199.4×226.1 mm, the AC16 is genuinely portable. Its IPx3 environmental rating provides moisture and dust protection suitable for varied venue conditions.
What are the typical uses for this speaker?
The AC16 excels as a floor monitor for live sound, a nearfield studio reference monitor, or a compact PA speaker for smaller venues and installations where space and portability are priorities.
