JBL AC15 Ultra Compact 2-Way Loudspeaker with 1 x 5.25 LF White SINGLE

JBL AC15 Ultra Compact 2-Way Loudspeaker with 1 x 5.25 LF White

The JBL AC15 is a genuinely portable 2-way active speaker system engineered for consistent, articulate output in compact installations. Its compact footprint—just 9.5 x 5.9 x 7.0 inches—combined with rugged construction makes it a practical choice for fixed or mobile audio applications where space is constrained but professional performance is required.

Design & Build Quality

The enclosure is constructed from multi-ply hardwood with a durable textured DuraFlex coating, offering genuine resistance to the wear and handling that mobile deployments demand. Dual Neutrik NL4 connectors plus screw terminals provide flexible input options, while built-in attachment points accommodate an optional U-bracket for mounting versatility.

Acoustic Performance & Power Handling

The speaker delivers 86 dB SPL at 1W/1m with a frequency range of 90 Hz to 18 kHz (±3 dB), covering the full spectrum needed for speech and music reinforcement. Rated continuous power handling of 150W with peak capacity at 600W ensures headroom for dynamic program material, while the 108 dB maximum SPL provides clean output without distortion in moderate-sized venues.

Key Features

• 1" dome tweeter with 90° x 90° coverage pattern
• 5.25" Symmetrical Field Geometry (SFG™) LF transducer with copper-capped pole piece
• Copper-clad aluminum edge-wound 1.5" voice coil
• System sensitivity: 86 dB SPL/1W/1m
• Frequency response: 90 Hz – 18 kHz (±3 dB)
• Power rating: 150W continuous / 300W program / 600W peak
• Maximum SPL: 108 dB (1m)
• 16-ohm impedance
• Dual Neutrik NL4 connectors plus screw terminals
• Compact dimensions: 241.3 x 150.3 x 177.8 mm
• Weight: 4.7 kg (10.5 lb)
• Mil-Std 810 and IPx3 (IEC529) environmental ratings

This single unit delivers professional-grade 2-way performance in a form factor that rewards efficiency, making it ideal for applications where reliability and compact installation matter most.
