Crown XTi 1002 Two-Channel 500W Power Amplifier
Description
Crown XTi 1002 Two-Channel 500W Power Amplifier
The Crown XTi 1002 delivers serious amplification muscle in a compact 3.5U rackmount footprint, with integrated cast-aluminum handles that make rack mounting and studio transport straightforward. This two-channel amplifier combines muscular output across multiple impedance configurations with professional-grade protection and control, making it an excellent fit for studio monitor systems, subwoofer amplification, and multi-zone recording environments. Built to run reliably session after session, the XTi 1002 sets the standard for performance and value in its class.
Power & Audio Performance
Power output scales intelligently across impedance loads: 500W per channel at 4 Ω stereo, 275W at 8 Ω, or 1400W bridged mono at 4 Ω for dedicated subwoofer duty. Audio specifications underscore transparency and low distortion—frequency response of 20 Hz–20 kHz, signal-to-noise ratio of 100 dB, THD below 0.5%, and a damping factor exceeding 500 ensures tight, controlled bass response and detailed reproduction across the full frequency spectrum for accurate mix translation.
Control & Protection for Studio Workflow
Peakx Plus limiters with adjustable threshold, attack, and release provide essential session protection and speaker safety while front-panel gain controls and an onboard LCD screen with DSP allow real-time adjustment and storage of up to 50 user-defined presets for different monitoring setups and room configurations. Three fan-speed modes let you minimize cooling noise during recording takes, while system monitoring displays AC line voltage and power-supply temperature for diagnostic confidence and troubleshooting.
Key Features
- 500W per channel at 4 Ω stereo; 700W at 2 Ω; 1400W bridged mono at 4 Ω
- Frequency response: 20 Hz – 20 kHz (+0 dB, –1 dB)
- Signal-to-noise ratio: 100 dB
- Total harmonic distortion: <0.5%
- Damping factor: >500 (20 Hz–20 kHz)
- Peakx Plus limiters with threshold, attack, and release control
- Front-panel channel level controls with gain adjustment
- Large LCD screen with onboard DSP and 50 user-definable presets
- Input impedance: 20 kΩ balanced, 10 kΩ unbalanced
- Three user-defined fan modes for application-specific cooling
- Integrated cast-aluminum handles and locking power cord clip
- 19" × 3.5" × 12.25" metal rackmount enclosure; 18.5 lbs
The XTi 1002 combines relentless power delivery, comprehensive limiting and DSP control, and professional build quality into an amplifier engineered for studio monitor systems, recording environments, and production facilities demanding transparent amplification and extended session reliability.
More Information
| Condition | New |
|---|---|
| Country of Manufacture | China |
Reviews
At a Glance
The Crown XTi 1002 is a pro-grade two-channel power amplifier delivering 500W per channel at 4 Ω with <0.5% THD, 100 dB signal-to-noise ratio, and damping factor exceeding 500 for tight, detailed bass and transparent audio reproduction. Its onboard DSP, adjustable Peakx Plus limiters, and 50 user-definable presets make it versatile across studio monitoring, mastering, and location recording setups where transparent amplification and real-time control matter. Choose it for a workhorse amplifier that combines studio-grade audio specs with roadworthy build and comprehensive metering.
Frequently Asked Questions
What power output should I expect at different impedances?
The XTi 1002 delivers 500W per channel at 4 Ω stereo, 275W at 8 Ω stereo, 700W at 2 Ω stereo, and 1400W bridged mono at 4 Ω—making it suitable for main PA speakers, monitors, and subwoofer applications.
What protection and control features does it include?
The amplifier features Peakx Plus limiters with adjustable threshold, attack, and release; front-panel gain controls; an onboard LCD screen with DSP; 50 user-definable presets; three fan-speed modes; and system monitoring that displays AC line voltage and power-supply temperature.
How portable is it for touring and installation work?
The XTi 1002 is designed for easy transport and installation: it fits in a compact 3.5U rackmount footprint (19" × 3.5" × 12.25"), weighs 18.5 lbs, and includes integrated cast-aluminum handles and a locking power cord clip.
What audio specs should I expect?
Frequency response is 20 Hz–20 kHz, signal-to-noise ratio is 100 dB, total harmonic distortion is below 0.5%, and the damping factor exceeds 500—delivering transparent, detailed reproduction with tight bass control.
Can I save and recall settings?
Yes, the onboard DSP allows you to create and store up to 50 user-defined presets, so you can save your preferred EQ, limiting, and gain settings for different venues or applications and recall them instantly.
