Crown DCI2X2400N DCI2X2400 Network

Crown DCI2X2400N DriveCore Install 2|2400 Network Amplifier

The Crown DCI2X2400N is a compact, rackmount network amplifier engineered for professional recording facilities and studio installations where networked mixing, remote DSP control, and transparent amplification are critical to session workflow. This 2-channel powerhouse delivers 2400W per channel across standard impedance loads and voltage configurations, making it ideal for tracking rooms, live recording setups, broadcast facilities, or distributed studio monitoring systems where networked control and integrated DSP processing streamline the production environment.

Power & Audio Performance

2400W per channel at 2, 4, 8, or 16 ohms—or 70/100V rms—provides clean, reliable headroom for studio monitor systems and recording applications while maintaining exceptional audio transparency. The amplifier achieves ±0.25dB frequency response (20Hz–20kHz at 8Ω) and 0.35% THD at full rated power, ensuring your mixes translate accurately across the entire audible spectrum with minimal coloration. A damping factor exceeding 5000 (20Hz–100Hz) yields precise, controlled bass response that captures the true character of your speakers and lets you hear what's actually on the track.

Networking & DSP Control

Native BLU Link digital audio transport via rear-panel RJ-45 connectors eliminates analog cable runs and integrates seamlessly into networked studio environments. HiQnet protocol over TCP/IP enables real-time remote monitoring, gain adjustment, and audio processing from any connected workstation, while onboard DSP capabilities include limiting, parametric EQs, delay, and a matrix mixer for creative signal routing and studio-grade processing without consuming rack space or adding latency.

Key Features

• 2-channel configuration with 2400W output per channel
• Compatible output impedances: 2Ω, 4Ω, 8Ω, 16Ω, 70Vrms, 100Vrms
• Frequency response ±0.25dB (8Ω, 20Hz–20kHz)
• Total harmonic distortion 0.35% at full rated power (20Hz–20kHz)
• Damping factor >5000 (20Hz–100Hz)
• BLU Link digital audio transport via RJ-45 networking
• HiQnet protocol control and monitoring over TCP/IP
• Built-in DSP: limiting, input/output EQs, delay, and matrix mixer
• Channel-independent impedance selection via rear-panel DIP switches
• Programmable GPIO ports for volume control, preset recall, and error reporting

The DCI2X2400N combines professional-grade amplification, networked intelligence, and onboard processing into a single chassis, making it the authoritative choice for studios that demand reliability, remote manageability, and transparent audio performance across recording and monitoring applications.
