BSS BLU-100 I/O device

BSS BLU-100 I/O Device

The BSS BLU-100 is a professional networked audio interface that brings studio-grade I/O expansion and low-latency routing to home studios and project facilities. This device excels in multiroom setups, distributed recording environments, and complex session workflows where flexible analog and digital I/O in a compact 1U rack format streamline capture and mixing. Its robust architecture leverages standard Category 5e cabling to extend audio across studio spaces without compromising signal integrity or introducing latency.

I/O Configuration & Connectivity

The unit provides 12 analog inputs and 8 analog outputs, each with software-configurable gain in 6dB steps up to +48dB and selectable phantom power per channel—essential for tracking microphones, instruments, and line-level sources across multiple rooms or isolation booths. Beyond audio, 12 control inputs and 6 logic outputs enable integration with external gear, automation systems, and monitoring solutions, while an RJ45 Ethernet connector supports distances up to 100 meters on Category 5e cable, making it ideal for wiring studios across multiple floors or remote monitoring setups.

Network Performance & Low-Latency Recording

The 48-channel digital audio bus operates with exceptionally low latency—only 0.23ms at 48kHz in normal operation and just 0.08ms pass-through latency—preserving tight synchronization across networked recording chains and live mixing sessions. The network topology supports up to 60 nodes, providing flexibility and redundancy for complex multiroom studio architectures. Power consumption remains minimal at under 55VA, and the unit operates reliably across standard AC mains (100–240V, 50/60Hz) and temperature ranges of 5–35°C.

Key Features

• 12 analog inputs with software-configurable gain (6dB steps, up to +48dB) and per-channel phantom power
• 8 analog outputs with independent control
• 12 control inputs and 6 logic outputs for external device integration
• 48-channel low-latency digital audio bus via standard Category 5e cabling
• RJ45 Ethernet connectivity; maximum 100m/300ft distance between devices
• Ultra-low latency: 0.23ms at 48kHz; pass-through latency 0.08ms at 48kHz
• Network architecture supports up to 60 nodes with fault tolerance
• Control Input Voltage 0–4.5V; Logic Output Voltage 0 or +5V unloaded (10mA source, 60mA sink)
• Compact 1U rack format (1.75" H × 19" W × 9.0" D); 6.4 lbs
• Low power consumption under 55VA; operates 5–35°C
• Mains voltage 100–240V AC, 50/60Hz compatible

The BLU-100 delivers professional-grade networked audio distribution with the reliability and performance standards required in demanding multiroom studio and recording environments.
