AMX MKP-106L-BL Massio Keypad 6-button landscape BLACK
Description
AMX MKP-106L-BL Massio Keypad 6-Button Landscape Black
The MKP-106L-BL is a compact landscape-oriented control keypad designed for integration into studio automation and system control applications. Its modest footprint and responsive button layout make it an intuitive addition to control environments where rack space is limited yet reliability cannot be compromised.
Network Integration & Power
This keypad connects via Ethernet with Power over Ethernet (PoE), eliminating the need for separate power infrastructure—a single 802.3af-compliant cable handles both communication and power delivery at 4.5 Watts typical consumption. Support for both DHCP and static IP addressing allows flexible deployment in diverse studio network environments, while the ability to daisy-chain up to two additional keypads using a single IP address simplifies multi-room or expanded system setups.
Hardware & Performance Specifications
The keypad houses 4 GB Flash storage, 256 MB DDRAM, and a 4 GB SD card slot, providing sufficient memory for custom programming and extended operation. Blue LED indicators on each of the six buttons offer clear visual feedback during use, while the black matte finish maintains a professional appearance in any studio control environment.
Key Features
- 6-button landscape configuration
- Dimensions: 3 7/16" × 4 11/16" × 9/16" (87.5 mm × 119 mm × 13.9 mm)
- Weight: 0.25 lbs
- Ethernet connectivity via Power over Ethernet (PoE)
- 802.3af standard compliance
- 4.5 Watts typical power consumption
- 4 GB Flash, 256 MB DDRAM, 4 GB SD card slot
- Blue LED button indication
- Daisy-chain capability for up to two additional keypads per IP address
- DHCP and static IP address support
- Black matte finish
The MKP-106L-BL combines efficient networking, low power draw, and expandable configuration—essential attributes for studio control systems demanding long-term reliability and straightforward integration into your recording environment.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The AMX MKP-106L-BL is a network-ready control interface built for studio automation and session management in professional recording environments. Home and commercial studios use it to trigger lighting, monitor routing, and system presets via a single Ethernet cable with integrated power delivery. Its compact footprint, blue LED feedback, and ability to daisy-chain multiple units make it ideal for customizing studio workflow without cluttering the workspace.
Who This Is For
Great for
- ✓ AV system control
- ✓ facility automation
- ✓ Live Performance
- ✓ Studio Sessions
Not the best pick for
- – musical performance
- – instrument amplification
Skill level: Professional
Frequently Asked Questions
How does the keypad connect to my system?
The MKP-106L-BL connects via a single Ethernet cable (802.3af-compliant Power over Ethernet), which supplies both network communication and power at 4.5 Watts typical draw. You can daisy-chain up to two additional keypads on the same IP address, and the keypad supports both DHCP and static IP addressing for flexible network deployment.
What size and weight is this keypad?
The keypad measures 3 7/16" × 4 11/16" × 9/16" (87.5 mm × 119 mm × 13.9 mm) and weighs 0.25 lbs, making it ideal for compact control rooms and installations where space is limited.
What programming and storage capability does it have?
The keypad includes 4 GB Flash storage, 256 MB DDRAM, and a 4 GB SD card slot, providing sufficient memory for custom programming and extended operation in complex AV and automation systems.
Can I see button status with this keypad?
Yes, each of the six buttons features a blue LED indicator that provides clear visual feedback during operation, helping you confirm commands in real time.
What professional environments is this keypad rated for?
The MKP-106L-BL is designed for AV system control, facility automation, live performance venues, and studio sessions where reliable, low-power network control is essential. Its black matte finish and compact design blend seamlessly into professional control rooms and performance spaces.
