AMX MET-13E-WH Metreau Keypad 13-button WHITE

AMX MET-13E-WH Metreau 13-Button White Keypad

The AMX MET-13E-WH is a compact networked control interface designed to integrate into studio monitoring, routing, and device management systems. Its streamlined white faceplate and tactile button layout provide tactile, responsive feedback through integrated LED indicators—essential for hands-on session control without requiring screen navigation.

Control Layout & Operation

This keypad features 13 buttons—twelve single-width and one double-width—allowing flexible command mapping for mixing console functions, speaker switching, input selection, or monitor mix recall. LED illumination on each button offers clear visual feedback, making it straightforward to identify active controls during recording sessions or mix work in any lighting condition.

Integration & Connectivity

The MET-13E-WH connects via RJ-45 Ethernet (10/100) and draws power directly from the network through 802.3af PoE, eliminating separate power supplies and studio cable clutter. Two rear-panel 8-pin IDC-type header connectors provide additional wired control options for custom integrations, and the unit mounts seamlessly into standard Decora-style wall plates for clean studio rack or control surface setups.

Key Features

• 13-button configuration (12 single-width, 1 double-width)
• LED backlighting for visual feedback
• RJ-45 Ethernet connectivity, 10/100
• Power over Ethernet (PoE) 802.3af, class 0
• Two 8-pin, 0.100" IDC-type male header connectors on rear panel
• Mounts into standard Decora-style wall plates
• Compact dimensions: 4" H × 1¾" W × 1" D
• Operating temperature range: 32°F to 104°F (0°C to 40°C)
• Operating humidity: 5% to 85%, non-condensing
• White finish (MET-13E-WH)

The MET-13E-WH delivers reliable networked control in a compact form factor that integrates naturally into studio control systems and recording setups.
