AMX HPX-U100-BTN Single Button module for Hydraport
Description
AMX HPX-U100-BTN Single Button Module for Hydraport
The HPX-U100-BTN is a compact control interface built for integration into AMX Hydraport systems in recording and production environments. This single-button module delivers tactile feedback through its illuminated pushbutton, making it straightforward to operate in studio control setups. Built as a purpose-built control solution, it provides reliable closure signaling and visual confirmation through its integrated LED indicator—useful for cueing, transport control, or session management in your recording chain.
Control Interface & Connectivity
The module features dual 2-position Phoenix connectors—one dedicated to the push-button closure circuit and one for the LED indicator. This connector-based design enables quick integration into modular Hydraport systems without permanent wiring, streamlining studio setup and reconfiguration between sessions. The separation of button and LED circuits allows independent control of visual feedback, giving you flexible routing options in your control rack.
Power & Operating Specifications
The LED back-light accepts +12 VDC nominal input with an operating range of 8–18 V, providing flexibility in power-supply scenarios and tolerance for voltage fluctuations common in studio environments. This wide input range ensures reliable indicator function across standard control voltage supplies typically found in recording system racks.
Key Features
- Single push-button with LED back-light indicator
- 2-position Phoenix connector for push-button closure
- 2-position Phoenix connector for LED input
- LED input voltage: +12 VDC nominal
- LED input voltage range: 8–18 V
- Designed as 1 HydraPort Unit module
- Single Button Module configuration
- Modular form factor for Hydraport integration
- Illuminated pushbutton for visual feedback
- Quick-disconnect Phoenix connectors for rapid installation
The HPX-U100-BTN delivers straightforward, dependable push-button control with integrated status indication—an essential component for building scalable, modular Hydraport-based control systems in your studio workflow.
