AKG PAE5 M Reference Phantom Power Module
Description
AKG PAE5 M Reference Phantom Power Module
The PAE5 M is a precision phantom power module engineered to deliver clean, stable power to large-diaphragm and instrument condenser microphones in studio and location recording setups. Its five-pin XLR architecture separates audio signal from control voltage, enabling remote LED ring activation—a critical advantage for tracking sessions where real-time mic status indication streamlines workflow without additional wiring runs.
System Design & Connectivity
This module features a dedicated five-pin XLR connector that decouples audio and control signals, allowing the LED ring to be remotely activated via 9–52V logic output from any compatible mixer or interface control system. The integrated gold-plated system connector securely interfaces with all DAM+ Series gooseneck modules and the HM1000 M hanging module, ensuring reliable contact and eliminating connection degradation over time. The wide voltage range (9–52V) accommodates most standard microphone preamps and mixing consoles in professional recording environments.
Audio Performance & Noise Control
The PAE5 M delivers transparent phantom power across a 20–20,000 Hz bandwidth with a switchable 150 Hz bass roll-off filter that reduces low-frequency rumble, handling noise, and proximity effect during overdubs and live tracking. Its electrical impedance of less than 600 Ω and recommended load impedance exceeding 2,000 Ω ensure stable operation with professional-grade microphone capsules and maintain signal integrity in the mix chain. RFi Shield technology provides high immunity to radio-frequency interference, critical in multi-channel recording sessions and environments with wireless systems or digital equipment.
Key Features
- Five-pin XLR connector with separate audio signal and control voltage feeds
- Remote LED ring activation via 9–52V logic output from automatic mixers
- Wide operating voltage range: 9 to 52V at 3.5 mA current draw
- Audio frequency bandwidth: 20–20,000 Hz
- Switchable bass roll-off filter at 150 Hz for noise reduction
- Electrical impedance: less than 600 Ω
- Recommended load impedance: greater than 2,000 Ω
- Gold-plated system connector for DAM+ Series gooseneck modules and HM1000 M hanging module
- RFi Shield technology for radio-frequency interference immunity
- Design optimized for fixed and mobile theatrical, worship, and conference room installations
The PAE5 M combines modular flexibility with professional-grade audio integrity, making it an essential component for recording and mixing systems that demand reliable phantom power distribution and integrated status indication during session work.
More Information
| Condition | New |
|---|---|
| Country of Manufacture | Taiwan |
Reviews
At a Glance
The AKG PAE5 M is a phantom power distribution module designed for professional recording and streaming setups using compatible AKG gooseneck or hanging microphones. It provides clean phantom power across the full audio bandwidth with a switchable 150 Hz bass roll-off to tame proximity effect and structure-borne noise in live recording environments. Select it for installations where you need modular, remote-controlled power management and integrated status indication without cluttering your signal chain.
Frequently Asked Questions
What does the five-pin XLR connector do differently from standard three-pin phantom power?
The five-pin design separates audio signal from control voltage, allowing the LED ring to be remotely activated via logic output from compatible automatic mixers. This eliminates the need for additional wiring runs to indicate microphone status in real time.
What microphones does the PAE5 M work with?
The PAE5 M integrates with all DAM+ Series gooseneck modules and the HM1000 M hanging module via its gold-plated system connector. It supplies standard phantom power (9–52V range) to any professional microphone that requires it.
Does it have a filter for reducing feedback and proximity effect?
Yes—the PAE5 M includes a switchable 150 Hz bass roll-off filter that reduces structure-borne noise and proximity effect in dynamic environments.
What kind of RF protection does it offer?
The module features RFi Shield technology for high immunity to radio-frequency interference, critical in broadcast and installed sound applications where multiple wireless systems operate nearby.
What voltage range does it support?
The PAE5 M operates across a 9–52V range at 3.5 mA current draw, accommodating most standard microphone mixers and automatic mixer control voltage outputs in professional installations.
