AKG GN15 ESP High Performance Modular Gooseneck Modules
Description
AKG GN15 ESP High Performance Modular Gooseneck Modules
The AKG GN15 ESP gooseneck modules deliver professional-grade engineering for capturing clear, controlled vocal and instrument recordings in the studio. The modular design allows precise placement and tonal shaping across vocals, drum overheads, instrument miking, and post-production voiceover work. These modules combine sonic clarity with controlled proximity effect and robust rejection of unwanted noise, making them reliable tools for capturing clean, focused sources in demanding recording sessions.
Design & Build
At 15cm (6 inches) in length with a 0.8" diameter, the compact gooseneck form factor enables flexible mic positioning without taking up valuable studio real estate. The standard 3-pin male XLR connector integrates seamlessly into existing recording chains and supports modular capsule swapping so you can dial in the right tonal character for each source and session.
Audio Performance & Connectivity
The 20 to 20,000 Hz frequency response captures full-spectrum audio detail for natural-sounding recordings, while the 2,000 Ohms recommended load impedance ensures optimal signal integrity with your preamp and audio interface. 9 to 52V phantom power support (drawing only 3.5 mA) works with standard mixing consoles, audio interfaces, and mic preamps without power supply hassles.
Key Features
- Length: 15cm (6 inches)
- Diameter: 0.8"
- Standard 3-pin male XLR connector
- Phantom power: 9 to 52V at 3.5 mA
- Frequency bandwidth: 20 to 20,000 Hz
- Recommended load impedance: 2,000 Ohms
- Compatible with DAM Series capsules: CK31, CK32, CK33, CK47, CK80
- Programmable mute switch: on/off, push-to-talk, push-to-mute modes
- LED ring MIC ON/OFF indicator
- Integrated bass rolloff filter (selectable)
- High immunity to radio-frequency interference
The modular architecture and comprehensive feature set make the GN15 ESP a versatile choice for vocal tracking, instrument recording, and overdub sessions where capsule swapping and precision positioning deliver session flexibility.
More Information
| Condition | New |
|---|
Reviews
At a Glance
The AKG GN15 ESP modular gooseneck captures full-spectrum audio (20–20,000 Hz) with controlled proximity effect and minimal feedback, ideal for home and commercial recording setups where you need a flexible, swappable-capsule solution. Studio and podcast producers value its modular design—swap DAM Series capsules to shape tone across spoken-word, acoustic, and instrument recording—and its selectable bass rolloff filter to tailor mixes without EQ automation. Low phantom-power draw (3.5 mA) and RF immunity keep recordings clean even in electrically noisy environments.
Frequently Asked Questions
What capsules are compatible with the GN15 ESP?
The GN15 ESP accepts AKG DAM Series capsules: CK31, CK32, CK33, CK47, and CK80. Each capsule offers different tonal characteristics, allowing you to swap modules to suit different applications without replacing the entire gooseneck.
What mute modes does it offer?
The GN15 ESP includes three programmable mute modes: on/off, push-to-talk, and push-to-mute. This flexibility accommodates broadcast, live performance, and installed-sound setups where muting control is essential.
Does it work with my existing console and wireless system?
Yes. The GN15 ESP supports 9 to 52V phantom power at only 3.5 mA draw, so it operates cleanly with standard mixing consoles and wireless systems without power supply complications. It connects via standard 3-pin male XLR.
How does the integrated bass rolloff filter help?
The selectable bass rolloff filter reduces low-frequency rumble and proximity-effect buildup, keeping vocals and speech clear and focused in live and studio recording without requiring separate EQ gear.
What is the frequency response and impedance?
The GN15 ESP delivers 20 to 20,000 Hz frequency response with a recommended 2,000 Ohms load impedance for optimal signal integrity in professional installations.
