Martin MAC Aura PXL, white finish, EPS

Martin MAC Aura PXL White Finish EPS

The Martin MAC Aura PXL is a compact, high-output moving light engineered for precision color work and dynamic pixel-mapped effects in mid-scale venues and touring rigs. Its lightweight frame and balanced yoke design make it quick to position and rig, while the dual-layer pixel system delivers rich wash coverage combined with intricate backlight control. This fixture suits lighting designers who demand both smooth color transitions and granular pixel-level manipulation without the footprint of larger moving heads.

Optical Performance & Light Output

With 19,000 lumens peak output from the light engine and fixture outputs of 10,500 lumens (wide) and 8,500 lumens (narrow), the MAC Aura PXL cuts through ambient light effectively across various throw distances. The 940,000 cd peak intensity in narrow mode ensures tight beam work and long-throw applications, while variable color temperature from 2,000 K to 10,000 K enables natural-looking tungsten-to-daylight transitions without sacrificing saturation.

Pixel Control & Design

RGBW solid-state color mixing across 19 individually controlled main beam pixels and 141 Aura backlight pixels provides exceptional versatility for pixel-mapped choreography, subtle color gradients, and synchronized multi-fixture effects. The 50 W LED engine with >50,000-hour minimum lifetime ensures reliable long-term operation while keeping thermal load minimal in densely packed rigs.

Key Features

• 19,000 lumens peak light engine output
• Fixture luminous output: 10,500 lumens (wide) / 8,500 lumens (narrow)
• Peak luminous intensity: 940,000 cd (narrow mode)
• Variable CCT: 2,000 K – 10,000 K (±200 K)
• RGBW solid-state color mixing
• 19 individually controlled main beam pixels
• 141 individually controlled Aura backlight pixels
• DMX-512, Art-Net, sACN, and Martin P3 protocol control
• Compact dimensions: 410 mm width (yoke) / 489 mm height
• Total LED power consumption: 50 W
• LED lifetime: >50,000 hours (to >70% output)
• Includes two omega brackets with 1/4 turn fasteners for rigging

The MAC Aura PXL combines punchy output with sophisticated pixel architecture, making it an intelligent choice for designers balancing fixture count, power draw, and creative control.
