Martin Exterior Wash Pro L QUAD, EU, Grey

Martin Exterior Wash Pro L QUAD, EU, Grey

The Martin Exterior Wash Pro L QUAD is a professional-grade LED wash fixture engineered for studio and live recording environments requiring reliable, color-accurate lighting control. Its compact yet robust aluminum housing delivers consistent performance across long session work and multi-day productions, making it ideal for capturing accurate video references, lighting talent during vocal and instrument recording, and maintaining precise color temperature control throughout production workflows where visual consistency and durability are critical.

Build Quality & Operational Reliability

This fixture features a cast aluminum housing with anodized and electrostatic powder-coated traffic grey finish, delivering IP66 protection and IK08 impact resistance for reliable studio and location use. The C5 High corrosion resistance rating (ISO 12944-6) ensures longevity in varied environmental conditions, while vibration resistance specifications—1.0g Sinusoidal, 0.7g RMS Random, and 3.0g ANSI—guarantee stable operation even during equipment relocation and multi-setup recording days.

Color Control & Recording Applications

The fixture delivers precise color mixing via 16 RGBW LEDs with an 8-degree beam angle, paired with RGB + CTC color temperature control spanning 1000 K to 12500 K in 50 K increments. Intensity control from 0–100% provides granular output adjustment across a wide color palette, enabling consistent lighting for video documentation, talent positioning, and reference footage without temperature shifts between takes or session dates.

Key Features

• 16 x RGBW LED with 8-degree beam angle
• IP66 protection rating and IK08 impact resistance
• Cast aluminum housing with anodized and electrostatic powder-coated finish (Traffic Grey RAL 7042)
• C5 High corrosion resistance (ISO 12944-6)
• Color temperature control: 1000 K – 12500 K in 50 K steps
• RGB + CTC color mixing with 0–100% intensity control
• Vibration resistance: 1.0g Sinusoidal, 0.7g RMS Random, 3.0g ANSI
• Dimensions: 165 mm (L) × 275 mm (W) × 370 mm (H); Weight: 12.4 kg
• Power: 2 m cable tail (H07RN-F 3G 1.0 mm²); 6-conductor DMX input/output
• Adjustable mounting bracket; operates in any orientation
• Minimum distance to illuminated surfaces: 0.1 m
• Effective Projected Area: 0.097 m² / 0.120 m²

The Martin Exterior Wash Pro L QUAD combines industrial-grade durability with sophisticated color control, delivering dependable lighting for recording sessions that demand both visual consistency and long-term operational reliability.
