JBL PD6322/95-WH Dual 12" three-way full-range loudspeaker (white)

JBL PD6322/95-WH Dual 12" Three-Way Full-Range Loudspeaker (White)

The PD6322/95-WH is a compact yet powerful three-way system engineered for recording studios, live tracking rooms, and critical listening environments requiring transparent, full-spectrum monitoring. Its dual 12" low-frequency section combined with dedicated midrange and high-frequency compression drivers delivers articulate, controlled output across the full spectrum—ideal for mix referencing and session work without consuming excessive floor space.

Monitoring Accuracy & Frequency Response

This system achieves a maximum continuous SPL of 134 dB with 140 dB peak capability, delivering sufficient headroom for dynamic material in medium rooms. The 90° × 50° coverage pattern creates a well-defined sweet spot for accurate mixing and critical listening, while the 49 Hz to 15 kHz frequency response (±3 dB) captures detail from low-end extension through high-frequency clarity without sacrificing the midrange clarity essential for vocal and instrumental balance.

Construction & Studio Durability

The enclosure features a powder-coated 14-gauge perforated steel grille with zinc-phosphate dipping and foam backing—built for the rigors of active studio environments and long-term reliability. Construction meets Mil-Std 810 environmental standards and carries IP-x3 protection per IEC529, suitable for isolated vocal booths, control rooms, and semi-permanent installations.

Key Features

• Dual JBL 2206H 12" vented gap cooled woofers with 4" voice coils
• CMCD-82H 8" cone midrange compression driver with dual 3" voice coils
• 2432H 1.5" exit compression driver with 3" voice coil
• Passive crossover at 1.5 kHz
• Nominal impedance: 4 ohms
• Long-term system power (bi-amp passive): 1200 W (4800 W peak)
• Frequency range (−10 dB): 41 Hz to 17 kHz
• Neutrik Speakon® NL8 connectors plus CE-compliant covered barrier strip terminals
• Coverage pattern: 90° × 50°
• Dimensions: 991 × 673 × 706 mm (39.0 × 26.5 × 27.8 in) in vertical orientation
• White finish with grille cloth backing
• Mil-Std 810 and IP-x3 rated construction

The PD6322/95 combines pro-grade component quality with practical proportions—a serious monitoring tool for producers and engineers requiring transparent, SPL-capable referencing in confined studio spaces.
