JBL PD6322/43-WH Dual 12" three-way full-range loudspeaker (white)

JBL PD6322/43-WH Dual 12" Three-Way Full-Range Loudspeaker (White)

The PD6322/43-WH is a professional three-way system engineered for accurate, consistent reproduction across studio monitoring and installed sound applications. Built around dual 12" low-frequency drivers and a sophisticated passive crossover design, this speaker delivers articulate midrange reproduction and controlled directivity that remains predictable across the listening plane. The white finish suits neutral studio environments where acoustic performance takes priority, while integrating cleanly into corporate, educational, and hospitality spaces.

Audio Performance & Coverage

This system achieves a continuous maximum SPL of 136 dB-SPL with 142 dB peaks in passive mode, accommodating dynamic program material and transient-rich sources in moderate to large tracking or mixing rooms. The 40° × 30° coverage pattern and ±3 dB frequency response from 49 Hz to 16 kHz ensure uniform tonal balance throughout the listening area, while the 1.7 kHz passive crossover maintains clean integration between the low, mid, and high-frequency sections for transparent stereo imaging and mix translation.

Driver Configuration & Build Quality

The dual JBL 2206H 12" Vented Gap Cooled (VGC) drivers with 4" voice coils provide controlled low-end extension down to 41 Hz, paired with a CMCD-82H 8" cone midrange driver and 2432H 1.5" compression driver for clear vocal presence and detailed instrumental reproduction. The cabinet features a powder-coated 14 gauge perforated steel grille with zinc-phosphate dip and foam backing, delivering durability for permanent studio installations and long-term session reliability.

Key Features

• Dual 12" low-frequency transducers with 4" voice coils and Vented Gap Cooled (VGC) design
• 8" cone midrange compression driver and 1.5" high-frequency compression driver
• 1.7 kHz passive crossover for seamless driver integration
• Frequency response ±3 dB: 49 Hz to 16 kHz
• Maximum SPL: 136 dB-SPL continuous average / 142 dB peak
• System sensitivity: 111 dB-SPL (1W @ 1m) in passive mode
• Coverage pattern: 40° × 30°
• 1200 W long-term power rating (4800 W peak) in bi-amp passive configuration
• Nominal impedance: 4 ohms
• Neutrik Speakon NL8 connectors plus CE-compliant barrier strip terminals
• Dimensions: 991 × 673 × 706 mm (39.0 × 26.5 × 27.8 inches)
• White powder-coated finish with reinforced perforated steel grille

The PD6322/43-WH combines proven JBL engineering with the mechanical robustness required for studio and installed sound, offering predictable performance and long-term reliability for critical listening and professional mixing applications.
