JBL PD6212/66-WH 12" two-way horn-loaded loudspeaker (white)

JBL PD6212/66-WH 12" Two-Way Horn-Loaded Loudspeaker (White)

The PD6212/66-WH is a compact, high-output two-way system engineered for studio monitoring, mixing environments, and control room applications where consistent acoustic behavior and efficient horn-loaded design are essential. Its focused directivity and exceptional sensitivity make it capable of delivering articulate, predictable reproduction across the listening area—ideal for critical mixing, mastering, and reference monitoring in professional recording spaces.

Acoustic Performance for Recording & Mixing

The system pairs a 12" low-frequency driver with 3" voice coil and 1.5" compression driver featuring a neodymium magnet and pure titanium diaphragm, yielding accurate transient response and extended headroom with minimal compression artifacts. The 60° x 60° coverage pattern and frequency extension to 80 Hz provide controlled directivity and deep low-end reproduction suitable for tracking, mixing, and near-field or mid-field monitoring applications in the recording studio.

Cabinet Construction & Studio Integration

The cabinet is constructed from void-free plywood with extensive internal bracing and rugged textured coating, minimizing cabinet resonance and acoustic coloration during long mixing sessions. Progressive Transition waveguides are rotatable for vertical or horizontal deployment, and the system includes twenty M10 threaded suspension points for precise acoustic positioning and isolation mounting to decouple the speaker from studio architecture.

Key Features

• 12" M222-8A low-frequency driver with 3" voice coil and horn-loaded design
• 2453H 1.5" compression driver with neodymium magnet and pure titanium diaphragm
• 60° x 60° coverage pattern for controlled, predictable sound distribution
• Frequency response extending to 80 Hz for extended low-frequency reach
• High sensitivity design with high continuous SPL capability
• Switchable bi-amped or passive operation for flexible system configurations
• Sophisticated steep-slope passive crossover network for accurate frequency division
• Speakon and CE-compliant covered barrier strip connectors for secure, professional connectivity
• Twenty M10 threaded suspension points for multiple rigging and mounting options
• Void-free plywood cabinet with extensive internal bracing and rugged textured coating
• Progressive Transition waveguides with rotatable orientation for vertical or horizontal deployment

The PD6212/66-WH combines efficient horn-loaded engineering, robust construction, and precise acoustic control to deliver reliable, transparent monitoring performance in professional recording and mixing environments.
