JBL PD6212/43-WH 12" two-way horn-loaded loudspeaker (white)

JBL PD6212/43-WH 12" Two-Way Horn-Loaded Loudspeaker (White)

The PD6212/43-WH is a versatile horn-loaded reference monitor and mid-range workhorse designed for recording studios, post-production facilities, and project spaces requiring professional-grade monitoring and reinforcement. Its trapezoidal cabinet with precisely angled 12.5-degree sides stacks efficiently for multi-speaker configurations, while the strategically placed 20-point suspension hardware enables flexible mounting in any orientation—ideal for desktop arrays, wall installations, or mobile tracking setups. This speaker delivers authoritative low-end clarity paired with controlled high-frequency detail, translating mixes accurately across the critical vocal and instrument ranges.

Acoustic Design & Performance

The combination of a JBL M222-8A 12" low-frequency driver with a 3" voice coil and a 2453H 1.5" high-frequency compression driver with a 4" voice coil produces exceptional clarity and efficiency across the critical vocal and instrument ranges. PT Progressive Transition waveguides maintain a consistent 40° × 30° coverage pattern for both drivers, ensuring even sound distribution and predictable off-axis response in studio and control-room environments, making critical listening positions equally reliable whether at the mixing console or around the tracking space.

Construction & Durability

The enclosure is fabricated from 16 mm exterior-grade 11-ply Finnish birch plywood, a material choice that balances rigidity with acoustic stability—essential for consistent monitoring and portable session work. Its robust construction withstands the demands of repeated setup/breakdown cycles and resists warping and delamination over extended studio service life, maintaining sonic integrity session after session.

Key Features

• 12-inch two-way horn-loaded loudspeaker with 40° × 30° horn coverage
• JBL M222-8A 12" LF driver with 3" voice coil
• 2453H 1.5" HF compression driver with 4" voice coil
• PT Progressive Transition waveguides for consistent pattern control
• Frequency response: 80 Hz to 18 kHz
• Power handling: 300 W continuous (1200 W peak), 100 hr rating
• High sensitivity design with high continuous SPL capability
• 16 mm 11-ply Finnish birch plywood enclosure
• Trapezoidal cabinet with 12.5° side angles for seamless array stacking
• 20-point suspension attachment (M10 threaded hardware): 5 top, 5 bottom, 4 per side, 2 rear
• Dimensions: 991 × 673 × 897 mm (39 × 26.5 × 35.3 in)
• Weight: 79.5 kg (175 lbs)
• Available in white finish

The PD6212/43-WH combines professional-grade drivers, precision waveguide engineering, and aircraft-quality plywood construction to deliver the sensitivity, tonal accuracy, and pattern control required in discerning recording and mixing environments.
