JBL PD6200/95-WH Two-way mid-high horn-loaded loudspeaker (white)

JBL PD6200/95-WH Two-Way Mid-High Horn-Loaded Loudspeaker

The PD6200/95-WH is a compact, rotatable mid-high speaker built for studio monitoring applications and small-venue mixing work where consistent pattern control and low distortion matter. Its horn-loaded design delivers controlled directivity across a wide bandwidth, making it ideal for near-field reference monitoring, mix verification, and accurate playback in control rooms and compact live tracking spaces. The white finish integrates cleanly into modern studio environments.

Acoustic Design & Monitoring Accuracy

The 90x50° coverage pattern combined with PT Progressive Transition waveguides ensures smooth frequency response and excellent pattern control, minimizing room reflections and maintaining consistent output across the sweet spot. This design enables clean, detailed reproduction at elevated output levels with minimal distortion—essential for critical listening and mix decisions in challenging room acoustics.

Drivers & Studio Flexibility

An 8" Differential Drive dual voice coil CMCD cone midrange compression driver handles midrange clarity and definition, while a 1.5" high-frequency compression driver with neodymium magnet and aluminum diaphragm delivers articulate, detailed highs for precision mixing. The speaker operates in biamplified or passive mode, and its rotatable waveguides permit either horizontal or vertical cabinet orientation to optimize coverage in asymmetrical control rooms or paired monitoring setups.

Key Features

• 8" Differential Drive dual voice coil CMCD cone midrange compression driver
• 1.5" exit high-frequency compression driver with neodymium magnet and aluminum diaphragm
• Frequency response: 200 Hz to 18 kHz
• 90x50° coverage pattern
• PT Progressive Transition waveguides for pattern control and smooth response
• 300W power rating
• Biamplified or full passive operation modes
• Rotatable waveguides for horizontal or vertical orientation
• NL4 speakON and Barrier Strip inputs
• Twenty M10 threaded suspension points for flexible mounting
• DuraFlex finish in white

The PD6200/95-WH combines proven compression driver technology with intelligent waveguide design to deliver pattern-controlled, distortion-free output across studio and small-venue recording applications.
