JBL PD595 -WH 15" 2-way full-range, 90 X 50

JBL PD595-WH 15" 2-Way Full-Range Loudspeaker

The PD595-WH is a trapezoidal, mid-sized full-range system engineered for studio monitoring, post-production suites, and medium-format control rooms where consistent output and precise coverage control matter. Its compact footprint and white finish integrate cleanly into varied studio environments while delivering professional sound pressure without excessive floor footprint demands.

Sonic Character & Output Capability

This system pairs a 2031H 15″ low-frequency driver with a 2432H 1.5″ compression driver, crossed over at 1300 Hz for clean midrange integration that translates well to playback systems. The 139 dB maximum SPL and 500 Watt RMS power handling provide sufficient headroom for detailed mixing and mastering workflows, while a 50–20,000 Hz frequency response covers the full audible spectrum with minimal external subwoofer dependency for most production scenarios.

Cabinet & Acoustic Design

The cabinet employs 18 mm exterior-grade 11-ply Finnish birch plywood with a DuraFlex™ finish, providing structural rigidity and resistance to the wear of studio environments. Its trapezoidal design with 10-degree side angles minimizes diffraction artifacts and eases monitor placement flexibility, while the rotatable 90° × 50° coverage pattern adapts to different room layouts, speaker positioning, and acoustic treatments.

Key Features

• 2031H 15″ low-frequency driver with 75 mm (3 in) voice coil
• 2432H 38 mm (1.5 in) compression driver with 75 mm (3 in) voice coil
• Rotatable 90° × 50° horizontal and vertical coverage pattern
• 8 ohm nominal impedance
• 300 Watt nominal / 500 Watt RMS maximum output power
• 139 dB maximum SPL
• 1300 Hz crossover frequency
• 50–20,000 Hz frequency response
• 18 mm 11-ply Finnish birch plywood enclosure with DuraFlex™ finish
• Trapezoidal cabinet with 10-degree side angles
• 30.8″ W × 26.4″ D × 30.8″ H dimensions
• 20 suspension attachment points with M10 threaded hardware

The PD595-WH combines substantial output capability with intelligent cabinet geometry and professional-grade materials, making it a reliable foundation for studios requiring accurate monitoring, mix translation, and long-term sonic consistency.
