JBL PD544 - WH 15" 2-way full-range, 40 X 40

JBL PD544-WH 15" 2-Way Full-Range Speaker

The PD544-WH is a compact, high-output passive speaker designed for studio monitoring applications and portable session work where consistent coverage and clarity matter. Its trapezoidal birch plywood cabinet and rotatable waveguide allow flexible placement on stands, wall mounting, or integration into larger monitoring systems, delivering professional output without the footprint of larger designs.

Sonic Character & Coverage

This two-way configuration delivers 133 dB SPL maximum output from a 15-inch horn-loaded woofer and 1.5-inch compression driver, with a tight 1,200 Hz crossover that ensures seamless midrange transition for accurate mix referencing. The 50 Hz – 20 kHz frequency response supports full-range monitoring while the 40° × 40° coverage pattern provides predictable, controlled dispersion ideal for medium-distance listening positions in control rooms and tracking spaces.

Cabinet & Durability

Built from 18 mm 11-ply Finnish birch plywood with trapezoidal geometry, the cabinet resists panel resonance and supports both stand and wall mounting for session flexibility. The rotatable waveguide pivots between horizontal and vertical orientations to optimize your monitoring angle, and the DuraFlex white finish resists wear in active studio environments while maintaining a professional appearance.

Key Features

• 2-way passive speaker system with switchable bi-amplified and passive crossover modes
• 15-inch horn-loaded low-frequency driver with 3-inch voice coil
• 1.5-inch compression driver with neodymium magnet and aluminum diaphragm
• Frequency Response: 50 – 20,000 Hz
• Maximum Output Level: 133 dB SPL
• Nominal Power Handling: 300W RMS / 500W Peak
• Nominal Impedance: 8 Ohm
• Crossover Frequency: 1,200 Hz with steep-slope design
• Coverage Pattern: 40° × 40°
• Enclosure: 18 mm 11-ply Finnish birch plywood, trapezoidal
• Dimensions: 30.8" W × 26.4" D × 30.8" H
• Rotatable waveguide for horizontal or vertical cabinet orientation
• Finish: DuraFlex, White

The PD544-WH combines rugged construction with flexible deployment, making it a dependable choice for control rooms, recording studios, and portable session rigs requiring compact, high-SPL monitoring coverage.
